Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	SwitchType	NumberofOutputs	Ratio-Input:Output	OutputConfiguration	OutputType	Interface	Voltage-Load	Voltage-Supply(Vcc/Vdd)	Current-Output(Max)	RdsOn(Typ)	InputType	Features	FaultProtection	OperatingTemperature	MountingType
HIP0084AS1 QUAD POWER DRIVERS W/SERIAL DIAG Harris Corporation	8,659	-	RFQ	Datasheet	Bulk	-	Active	Relay, Solenoid Driver	4	1:1	Low Side	N-Channel	Serial, SPI	3.5V ~ 5.5V	Not Required	2A, 5A	-	Inverting	Latch Function, Slew Rate Controlled	Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit	-40°C ~ 125°C (TA)	Through Hole
CA3272Q QUAD-GATED INVERTING POWER DRIVE Harris Corporation	5,782	-	RFQ	Datasheet	Bulk	-	Active	Relay, Solenoid Driver	4	1:1	Low Side	Bipolar	On/Off	60V	7V	600mA	-	Inverting	Load Discharge, Status Flag	Current Limiting (Fixed), Over Temperature	-40°C ~ 125°C (TA)	Surface Mount
SP710AS BUFFER/INVERTER BASED PERIPHERAL Harris Corporation	8,569	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	1	1:1	-	N-Channel	-	4V ~ 16V	Not Required	800mA	-	Non-Inverting	-	Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit	-40°C ~ 125°C (TA)	Through Hole
HIP0050IP 0.3A/50V OCTAL LOW SIDE POWER DR Harris Corporation	2,125	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	8	1:1	Low Side	N-Channel	On/Off	5V	Not Required	2A	2Ohm	Non-Inverting	Status Flag	Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit	-40°C ~ 85°C (TA)	Through Hole
HIP0050IB-HC 0.3A/50V OCTAL LOW SIDE POWER DR Harris Corporation	2,016	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	8	1:1	Low Side	N-Channel	SPI	5V	Not Required	2A	2Ohm	Non-Inverting	Status Flag	Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit	-40°C ~ 85°C (TA)	Surface Mount
HIP1090AS PROTECTED HIGH SIDE POWER SWITCH Harris Corporation	7,830	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	1	1:1	High Side	N-Channel	On/Off	4V ~ 16V	Not Required	1A	-	Non-Inverting	-	Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit	-40°C ~ 125°C (TA)	Through Hole
HIP0050IB96 0.3A/50V OCTAL LOW SIDE POWER DR Harris Corporation	31,000	-	RFQ	Datasheet	Bulk	-	Active	Latched Driver	8	1:1	Low Side	N-Channel	On/Off, Parallel, SPI, Strobe	5V	Not Required	2A	2Ohm	Inverting	Latch Function, Status Flag	Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit	-40°C ~ 85°C (TA)	Surface Mount
CA3272AM QUAD-GATED INVERTING POWER DRIVE Harris Corporation	3,794	-	RFQ	Datasheet	Bulk	-	Active	Relay, Solenoid Driver	4	1:1	Low Side	Bipolar	On/Off	15V	7V	600mA	-	Non-Inverting	Load Discharge, Status Flag	Current Limiting (Fixed), Over Temperature, Over Voltage	-40°C ~ 125°C (TA)	Surface Mount
CA3292AM96 QUAD-GATED INVERTING POWER DRIVE Harris Corporation	558	-	RFQ	Datasheet	Bulk	-	Active	Relay, Solenoid Driver	4	1:1	Low Side	Bipolar	On/Off	15V	7V	600mA	-	Non-Inverting	Load Discharge, Status Flag	Current Limiting (Fixed), Over Temperature, Over Voltage	-40°C ~ 125°C (TA)	Surface Mount
CA3272QX INVERTING POWER DRIVER Harris Corporation	383	-	RFQ	Datasheet	Bulk	-	Active	Relay, Solenoid Driver	4	1:1	Low Side	Bipolar	On/Off	60V	7V	600mA	-	Inverting	Load Discharge, Status Flag	Current Limiting (Fixed), Over Temperature	-40°C ~ 125°C (TA)	Surface Mount
DG125BP 5 CHANNEL DRIVER SWICH Harris Corporation	3,345	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	5	1:1	-	P-Channel	On/Off	33V	Not Required	-	100Ohm	Inverting, Non-Inverting	-	-	-20°C ~ 85°C	Through Hole
CA3274E POWER SWITCH WITH CURR LIMITER Harris Corporation	3,756	-	RFQ	Datasheet	Bulk	-	Active	Relay, Solenoid Driver	1	1:1	-	P-Channel	On/Off	16V	Not Required	200mA	-	Non-Inverting	Status Flag	Current Limiting	-40°C ~ 85°C (TA)	Through Hole
