Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	SwitchType	NumberofOutputs	Ratio-Input:Output	OutputConfiguration	OutputType	Interface	Voltage-Load	Voltage-Supply(Vcc/Vdd)	Current-Output(Max)	RdsOn(Typ)	InputType	Features	FaultProtection	OperatingTemperature	MountingType
NX5P2924BUK012 LOGIC CONTROLLED HIGH-SIDE POWER Freescale Semiconductor	200,974	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	1	1:1	High Side	N-Channel	On/Off	0.8V ~ 5.5V	-	2.5A	14mOhm	Inverting	Load Discharge, Slew Rate Controlled	-	-40°C ~ 85°C (TA)	Surface Mount
MC33397DWR2 BUFFER/INVERTER PERIPHL DRIVER Freescale Semiconductor	53,850	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	6	1:1	Low Side	N-Channel	Parallel, SPI	4.75V ~ 5.25V	-	1.5A	700mOhm	Non-Inverting	-	Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage	-40°C ~ 125°C (TA)	Surface Mount
MC33397DW BUFFER/INVERTER BASED PERIPHERAL Freescale Semiconductor	1,050	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	6	1:1	Low Side	N-Channel	Parallel, SPI	4.75V ~ 5.25V	-	1.5A	700mOhm	Non-Inverting	-	Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage	-40°C ~ 125°C (TA)	Surface Mount
MC33988CHFK HIGH-SIDE SWITCH, 12V, DUAL 8MOH Freescale Semiconductor	107	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	2	1:2	High Side	N-Channel	SPI	6V ~ 27V	4.5V ~ 5.5V	-	8mOhm (Max)	-	Slew Rate Controlled, Watchdog Timer	Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage	-40°C ~ 150°C (TJ)	Surface Mount
MC06XSD200FK HIGH-SIDE SWITCH, 36V, DUAL 6MOH Freescale Semiconductor	2,382	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	2	1:2	High Side	N-Channel	SPI	8V ~ 36V	3V ~ 5.5V	9A	6mOhm	-	Internal PWM, Slew Rate Controlled	Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage	-40°C ~ 150°C (TJ)	Surface Mount
MC10XS4200FK HIGH-SIDE SWITCH, 24V, DUAL 10MO Freescale Semiconductor	3,413	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	2	1:1	High Side	N-Channel	SPI	8V ~ 36V	3V ~ 5.5V	6A	10mOhm (Max)	-	Internal PWM, Slew Rate Controlled, Watchdog Timer	Current Limiting (Fixed), Open Load Detect, Over Temperature, UVLO	-40°C ~ 125°C (TA)	Surface Mount
MC08XSF421EK HIGH-SIDE SWITCH, 12V, DUAL 8MOH Freescale Semiconductor	3,533	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	4	1:1	High Side	N-Channel	SPI	7V ~ 18V	4.5V ~ 5.5V	5.5A, 11A	8mOhm, 21mOhm	-	Slew Rate Controlled	Current Limiting (Fixed), Open Load Detect, Over Temperature	-40°C ~ 125°C (TA)	Surface Mount
MCZ33880EGR2 BRUSH DC MOTOR CONTROLLER, 2A, P Freescale Semiconductor	3,401	-	RFQ		Bulk	-	Active	General Purpose	8	1:8	High Side or Low Side	N-Channel	SPI	5.5V ~ 24.5V	4.75V ~ 5.25V	800mA	550mOhm	-	-	Current Limiting (Fixed), Open Load Detect, Over Voltage	-40°C ~ 150°C (TJ)	Surface Mount
MC17XS6500EK BUFFER/INVERTER BASED MOSFET DRI Freescale Semiconductor	3,706	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	6	1:1	High Side	N-Channel	SPI	7V ~ 18V	4.5V ~ 5.5V	-	17mOhm	-	Internal PWM	Current Limiting (Fixed), Open Load Detect, Over Temperature	-40°C ~ 125°C (TA)	Surface Mount
MC17XSF500EK HIGH-SIDE SWITCH, 18V, PENTA 17M Freescale Semiconductor	3,481	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	5	1:1	High Side	N-Channel	SPI	7V ~ 18V	4.5V ~ 5.5V	5.5A	17mOhm	-	-	Current Limiting (Fixed), Open Load Detect, Over Temperature	-40°C ~ 125°C (TA)	Surface Mount
MC22XSD200BEK HIGH-SIDE SWITCH, 36V, DUAL 22MO Freescale Semiconductor	2,739	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	2	1:1	High Side	N-Channel	SPI	8V ~ 36V	3.3V ~ 5V	3A	22mOhm	-	Slew Rate Controlled	Open Load Detect, Over Temperature	-40°C ~ 125°C (TA)	Surface Mount
MC07XSF517EK HIGH-SIDE SWITCH, 18V, TRIPLE 7M Freescale Semiconductor	2,222	-	RFQ	Datasheet	Bulk	-	Active	General Purpose	6	1:1	High Side	N-Channel	SPI	7V ~ 18V	4.5V ~ 5.5V	5.5A, 11A	7mOhm, 17mOhm	CMOS	Internal PWM	Current Limiting (Fixed), Open Load Detect, Over Temperature	-40°C ~ 125°C (TA)	Surface Mount
