Mfr. Part #	Availability	Price	Quantity	Datasheet	Package/Case	Packaging	Series	ProductStatus	Capacitance	Tolerance	VoltageRating-AC	VoltageRating-DC	DielectricMaterial	ESR(EquivalentSeriesResistance)	OperatingTemperature	MountingType	Size/Dimension	Height-Seated(Max)	Termination	LeadSpacing	Applications	Ratings
B32560J1334K000 CAP FILM 0.33UF 10% 100VDC 2DIP EPCOS - TDK Electronics	31,302	-	RFQ	Datasheet	2-DIP	Bulk	B3256* - MKT SilverCap™	Not For New Designs	0.33 µF	±10%	63V	100V	Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked	-	-55°C ~ 125°C	Through Hole	0.354 L x 0.106 W (9.00mm x 2.70mm)	0.224 (5.70mm)	PC Pins	0.295 (7.50mm)	General Purpose	-
B32620A3223J000 CAP FILM 0.022UF 5% 250VDC RAD EPCOS - TDK Electronics	5,326	-	RFQ	Datasheet	Radial	Bulk	B3262* - MKP High Pulse (stacked)	Active	0.022 µF	±5%	140V	250V	Polypropylene (PP), Metallized - Stacked	-	-55°C ~ 105°C	Through Hole	0.394 L x 0.157 W (10.00mm x 4.00mm)	0.335 (8.50mm)	PC Pins	0.295 (7.50mm)	High Pulse, DV/DT	-
MMK15104K400B04L4BULK CAP FILM 0.1UF 10% 400VDC RADIAL KEMET	4,781	-	RFQ	Datasheet	Radial	Box	MMK	Active	0.1 µF	±10%	200V	400V	Polyester, Metallized	-	-55°C ~ 100°C	Through Hole	0.709 L x 0.217 W (18.00mm x 5.50mm)	0.413 (10.50mm)	PC Pins	0.591 (15.00mm)	General Purpose	-
R76QF147050H3J CAP FILM 4700PF 5% 1KVDC RADIAL KEMET	4,415	-	RFQ	Datasheet	Radial	Bulk	R76H	Active	4700 pF	±5%	600V	1000V (1kV)	Polypropylene (PP), Metallized	135 mOhms	-55°C ~ 125°C	Through Hole	0.512 L x 0.197 W (13.00mm x 5.00mm)	0.437 (11.10mm)	PC Pins	-	Automotive; High Frequency, Switching; High Pulse, DV/DT	AEC-Q200
B32672L8332J000 CAP FILM 3300PF 5% 2KVDC RADIAL EPCOS - TDK Electronics	4,112	-	RFQ	Datasheet	Radial	Bulk	B3267L - MKP High Current	Active	3300 pF	±5%	700V	2000V (2kV)	Polypropylene (PP), Metallized	-	-55°C ~ 110°C	Through Hole	0.709 L x 0.197 W (18.00mm x 5.00mm)	0.413 (10.50mm)	PC Pins	0.591 (15.00mm)	High Frequency, Switching; High Pulse, DV/DT	-
B32620A4682J000 CAP FILM 6800PF 5% 400VDC RADIAL EPCOS - TDK Electronics	3,968	-	RFQ	Datasheet	Radial	Bulk	B3262* - MKP High Pulse (stacked)	Active	6800 pF	±5%	200V	400V	Polypropylene (PP), Metallized - Stacked	-	-55°C ~ 105°C	Through Hole	0.394 L x 0.157 W (10.00mm x 4.00mm)	0.335 (8.50mm)	PC Pins	0.295 (7.50mm)	High Pulse, DV/DT	-
B32671L6333J000 CAP FILM 0.033UF 5% 630VDC RAD EPCOS - TDK Electronics	3,528	-	RFQ	Datasheet	Radial	Bulk	B3267L - MKP High Current	Active	0.033 µF	±5%	250V	630V	Polypropylene (PP), Metallized	-	-55°C ~ 110°C	Through Hole	0.512 L x 0.197 W (13.00mm x 5.00mm)	0.433 (11.00mm)	PC Pins	0.394 (10.00mm)	High Frequency, Switching; High Pulse, DV/DT	AEC-Q200
B32620A4103J000 CAP FILM 10000PF 5% 400VDC RAD EPCOS - TDK Electronics	2,549	-	RFQ	Datasheet	Radial	Bulk	B3262* - MKP High Pulse (stacked)	Active	10000 pF	±5%	200V	400V	Polypropylene (PP), Metallized - Stacked	-	-55°C ~ 105°C	Through Hole	0.394 L x 0.157 W (10.00mm x 4.00mm)	0.335 (8.50mm)	PC Pins	0.295 (7.50mm)	High Pulse, DV/DT	-
FKP2J016801J00JSSD CAP FILM 6800PF 5% 630VDC RAD WIMA	2,370	-	RFQ	Datasheet	Radial	Bulk	-	Active	6800 pF	±5%	250V	630V	Polypropylene (PP)	-	-55°C ~ 100°C	Through Hole	0.283 L x 0.283 W (7.20mm x 7.20mm)	0.335 (8.50mm)	PC Pins	0.197 (5.00mm)	High Frequency, Switching; High Pulse, DV/DT	-
B32672L8392J000 CAP FILM 3900PF 5% 2KVDC RADIAL EPCOS - TDK Electronics	2,209	-	RFQ	Datasheet	Radial	Bulk	B3267L - MKP High Current	Active	3900 pF	±5%	700V	2000V (2kV)	Polypropylene (PP), Metallized	-	-55°C ~ 110°C	Through Hole	0.709 L x 0.197 W (18.00mm x 5.00mm)	0.413 (10.50mm)	PC Pins	0.591 (15.00mm)	High Frequency, Switching; High Pulse, DV/DT	-
ECQ-UAAF333M CAP FILM 0.033UF 20% 275VAC RADI Panasonic Electronic Components	2,038	-	RFQ	Datasheet	Radial	Bulk	ECQ-UA	Active	0.033 µF	±20%	275V	-	Polypropylene (PP), Metallized	-	-40°C ~ 110°C	Through Hole	0.602 L x 0.197 W (15.30mm x 5.00mm)	0.472 (12.00mm)	PC Pins	0.492 (12.50mm)	EMI, RFI Suppression	X2
R46KF215000N0K CAP FILM 0.015UF 10% 560VDC RAD KEMET	1,985	-	RFQ	Datasheet	Radial	Box	R46	Active	0.015 µF	±10%	275V	560V	Polypropylene (PP), Metallized	-	-40°C ~ 110°C	Through Hole	0.512 L x 0.157 W (13.00mm x 4.00mm)	0.358 (9.10mm)	PC Pins	0.394 (10.00mm)	EMI, RFI Suppression	X2
B32652A1472K000 CAP FILM 4700PF 10% 1.6KVDC RAD EPCOS - TDK Electronics	1,788	-	RFQ	Datasheet	Radial	Bulk	B3265* - MKP General Purpose	Active	4700 pF	±10%	500V	1600V (1.6kV)	Polypropylene (PP), Metallized	-	-55°C ~ 100°C	Through Hole	0.709 L x 0.236 W (18.00mm x 6.00mm)	0.433 (11.00mm)	PC Pins	0.591 (15.00mm)	Automotive; DC Link, DC Filtering; High Pulse, DV/DT; Snubber	AEC-Q200
B32521C6104K CAP FILM 0.1UF 10% 400VDC RADIAL EPCOS - TDK Electronics	1,725	-	RFQ	Datasheet	Radial	Bulk	B3252* - MKT General Purpose	Not For New Designs	0.1 µF	±10%	200V	400V	Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked	-	-55°C ~ 125°C	Through Hole	0.512 L x 0.236 W (13.00mm x 6.00mm)	0.472 (12.00mm)	PC Pins	0.394 (10.00mm)	Automotive; EMI, RFI Suppression	-
R463I24700001M CAP FILM 0.047UF 20% 630VDC RAD KEMET	1,650	-	RFQ	Datasheet	Radial	Bulk	R46	Active	0.047 µF	±20%	310V	630V	Polypropylene (PP), Metallized	-	-40°C ~ 110°C	Through Hole	0.709 L x 0.197 W (18.00mm x 5.00mm)	0.437 (11.10mm)	PC Pins	0.591 (15.00mm)	EMI, RFI Suppression	X2
ECW-FE2W334K CAP FILM 0.33UF 10% 450VDC RAD Panasonic Electronic Components	1,488	-	RFQ	Datasheet	Radial	Bulk	ECWFE	Active	0.33 µF	±10%	84V	450V	Polypropylene (PP), Metallized	-	-40°C ~ 105°C	Through Hole	0.512 L x 0.236 W (13.00mm x 6.00mm)	0.472 (12.00mm)	PC Pins	0.394 (10.00mm)	EMI, RFI Suppression; High Frequency, Switching; High Pulse, DV/DT	-
ECH-U1563GC9 CAP FILM 0.056UF 2% 100VDC 2416 Panasonic Electronic Components	3,490	-	RFQ	Datasheet	2416 (6041 Metric)	Tape & Reel (TR),Cut Tape (CT)	ECH-U(C)	Active	0.056 µF	±2%	40V	100V	Polyphenylene Sulfide (PPS), Metallized - Stacked	-	-55°C ~ 105°C	Surface Mount	0.236 L x 0.161 W (6.00mm x 4.10mm)	0.118 (3.00mm)	Solder Pads	-	General Purpose	-
MKS2B033301A00MSSD CAP FILM 0.33UF 20% 50VDC RAD WIMA	6,140	-	RFQ	Datasheet	Radial	Bulk	-	Active	0.33 µF	±20%	30V	50V	Polyester, Polyethylene Terephthalate (PET), Metallized	-	-55°C ~ 100°C	Through Hole	0.283 L x 0.098 W (7.20mm x 2.50mm)	0.256 (6.50mm)	PC Pins	0.197 (5.00mm)	Automotive	AEC-Q200
MMK5224K100J02L4BULK CAP FILM 0.22UF 10% 100VDC RAD KEMET	4,597	-	RFQ	Datasheet	Radial	Box	MMK	Active	0.22 µF	±10%	63V	100V	Polyester, Metallized	-	-55°C ~ 100°C	Through Hole	0.283 L x 0.138 W (7.20mm x 3.50mm)	0.315 (8.00mm)	PC Pins	0.197 (5.00mm)	General Purpose	-
B32522C3224J000 CAP FILM 0.22UF 5% 250VDC RADIAL EPCOS - TDK Electronics	4,060	-	RFQ	Datasheet	Radial	Bulk	B3252* - MKT General Purpose	Active	0.22 µF	±5%	160V	250V	Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked	-	-55°C ~ 125°C	Through Hole	0.709 L x 0.197 W (18.00mm x 5.00mm)	0.413 (10.50mm)	PC Pins	0.591 (15.00mm)	Automotive; EMI, RFI Suppression	AEC-Q200
