Optoisolators - Transistor, Photovoltaic Output- Page 15

MAX3232IDR PIC18F25K22T-I/SO 5-160558-2 ESD9B5.0ST5G

Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	NumberofChannels	Voltage-Isolation	CurrentTransferRatio(Min)	CurrentTransferRatio(Max)	TurnOn/TurnOffTime(Typ)	Rise/FallTime(Typ)	InputType	OutputType	Voltage-Output(Max)	Current-Output/Channel	Voltage-Forward(Vf)(Typ)	Current-DCForward(If)(Max)	VceSaturation(Max)	OperatingTemperature	MountingType
CNY17-3 OPTOISO 5KV TRANS W/BASE 6DIP Lite-On Inc.	2,363	-	RFQ	Datasheet	Tube	CNY17	Active	1	5000Vrms	100% @ 10mA	200% @ 10mA	-	5µs, 5µs	DC	Transistor with Base	70V	150mA	1.45V	60 mA	300mV	-55°C ~ 100°C	Through Hole
Q817C DIP 4PIN DC INPUT PHOTOTRANSISTO QT Brightek (QTB)	780	-	RFQ	Datasheet	Tube	Q817	Active	1	5000Vrms	200% @ 5mA	400% @ 5mA	-	6µs, 8µs	DC	Transistor	35V	50mA	1.24V	60 mA	200mV	-55°C ~ 110°C	Through Hole
LTV-826S OPTOISOLATOR 5KV 2CH TRANS 8-SMD Lite-On Inc.	2,064	-	RFQ	Datasheet	Tube	LTV-826	Active	2	5000Vrms	50% @ 5mA	600% @ 5mA	-	4µs, 3µs	DC	Transistor	80V	50mA	1.2V	50 mA	200mV	-30°C ~ 100°C	Surface Mount
LTV-815 OPTOISOLTR 5KV DARLINGTON 4-DIP Lite-On Inc.	3,230	-	RFQ	Datasheet	Tube	LTV-8x5	Active	1	5000Vrms	600% @ 1mA	7500% @ 1mA	-	60µs, 53µs	DC	Darlington	35V	80mA	1.2V	50 mA	1V	-30°C ~ 100°C	Through Hole
TLP785(GB,F) OPTOISOLATR 5KV TRANSISTOR 4-DIP Toshiba Semiconductor and Storage	3,957	-	RFQ	Datasheet	Tube	-	Active	1	5000Vrms	100% @ 5mA	600% @ 5mA	3µs, 3µs	2µs, 3µs	DC	Transistor	80V	50mA	1.15V	60 mA	400mV	-55°C ~ 110°C	Through Hole
SFH618A-4X OPTOISOLATOR 5.3KV TRANS 4DIP Isocom Components 2004 LTD	2,098	-	RFQ	Datasheet	Tube	-	Active	1	5300Vrms	160% @ 1mA	320% @ 1mA	-	4µs, 3µs	DC	Transistor	55V	50mA	1.5V (Max)	50 mA	400mV	-30°C ~ 100°C	Through Hole
LTV-827S OPTOISOLATOR 5KV 2CH TRANS 8-SMD Lite-On Inc.	2,616	-	RFQ	Datasheet	Tube	LTV-8x7	Active	2	5000Vrms	50% @ 5mA	600% @ 5mA	-	4µs, 3µs	DC	Transistor	35V	50mA	1.2V	50 mA	200mV	-30°C ~ 110°C	Surface Mount
CNY17F-3S OPTOISOLTR 5KV TRANSISTOR 6-SMD Lite-On Inc.	2,788	-	RFQ	Datasheet	Tube	CNY17F	Active	1	5000Vrms	100% @ 10mA	200% @ 10mA	-	5µs, 5µs	DC	Transistor	70V	150mA	1.45V	60 mA	300mV	-55°C ~ 100°C	Surface Mount
LTV-814HS OPTOISOLATR 5KV TRANSISTOR 4-SMD Lite-On Inc.	2,091	-	RFQ	Datasheet	Tube	-	Active	1	5000Vrms	20% @ 100mA	80% @ 100mA	-	4µs, 3µs	AC, DC	Transistor	35V	80mA	1.4V	150 mA	200mV	-30°C ~ 100°C	Surface Mount
FOD817A OPTOISOLATOR 5KV TRANSISTOR 4DIP onsemi	2,091	-	RFQ	Datasheet	Tube	-	Active	1	5000Vrms	80% @ 5mA	160% @ 5mA	-	4µs, 3µs	DC	Transistor	70V	50mA	1.2V	50 mA	200mV	-55°C ~ 110°C	Through Hole
SFH618A-3X OPTOISOLATOR 5.3KV TRANS 4DIP Isocom Components 2004 LTD	2,183	-	RFQ	Datasheet	Tube	-	Active	1	5300Vrms	100% @ 1mA	200% @ 1mA	-	4µs, 3µs	DC	Transistor	55V	50mA	1.5V (Max)	50 mA	400mV	-30°C ~ 100°C	Through Hole
TLP785(GR,F) OPTOISOLATR 5KV TRANSISTOR 4-DIP Toshiba Semiconductor and Storage	2,643	-	RFQ	Datasheet	Tube	-	Active	1	5000Vrms	100% @ 5mA	300% @ 5mA	3µs, 3µs	2µs, 3µs	DC	Transistor	80V	50mA	1.15V	60 mA	400mV	-55°C ~ 110°C	Through Hole
TLP785(BL,F) OPTOISOLATR 5KV TRANSISTOR 4-DIP Toshiba Semiconductor and Storage	2,667	-	RFQ	Datasheet	Tube	-	Active	1	5000Vrms	200% @ 5mA	600% @ 5mA	3µs, 3µs	2µs, 3µs	DC	Transistor	80V	50mA	1.15V	60 mA	400mV	-55°C ~ 110°C	Through Hole
PS2561A-1-A OPTOISOLATOR 5KV TRANS 4DIP CEL	3,404	-	RFQ	Datasheet	Tube	NEPOC	Active	1	5000Vrms	50% @ 5mA	400% @ 5mA	-	3µs, 5µs	DC	Transistor	70V	30mA	1.2V	30 mA	300mV	-55°C ~ 100°C	Through Hole
TLP2703(TP,E OPTOISO 5KV DARLINGTON SO6L Toshiba Semiconductor and Storage	3,018	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	1	5000Vrms	900% @ 500µA	8000% @ 500µA	330ns, 2.5µs	-	DC	Darlington	18V	80mA	1.47V	20 mA	-	-40°C ~ 125°C	Surface Mount
PS2561AL1-1-L-A OPTOISOLATOR 5KV TRANS 4DIP Renesas Electronics America Inc	2,881	-	RFQ	Datasheet	Tube	NEPOC	Active	1	5000Vrms	200% @ 5mA	400% @ 5mA	-	3µs, 5µs	DC	Transistor	70V	30mA	1.2V	30 mA	300mV	-55°C ~ 100°C	Through Hole
CNY17-3S OPTOISO 5KV TRANS W/BASE 6SMD Lite-On Inc.	3,348	-	RFQ	Datasheet	Tube	CNY17	Active	1	5000Vrms	100% @ 10mA	200% @ 10mA	-	5µs, 5µs	DC	Transistor with Base	70V	150mA	1.45V	60 mA	300mV	-55°C ~ 100°C	Surface Mount
HCPL-817-300E OPTOISOLATOR 5KV TRANSISTOR 4SMD Broadcom Limited	2,097	-	RFQ	Datasheet	Tube	-	Active	1	5000Vrms	50% @ 5mA	600% @ 5mA	-	4µs, 3µs	DC	Transistor	70V	50mA	1.2V	50 mA	200mV	-30°C ~ 100°C	Surface Mount
PS2706-1-F3-A OPTOISOLATOR 3.75KV DARL 4SMD Renesas Electronics America Inc	2,443	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	NEPOC	Active	1	3750Vrms	200% @ 1mA	-	-	200µs, 200µs	AC, DC	Darlington	40V	200mA	1.1V	50 mA	1V	-55°C ~ 100°C	Surface Mount
CPC1001NTR OPTOISOLATOR 1.5KV TRANS 4SMD IXYS Integrated Circuits Division	3,924	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	1	1500Vrms	100% @ 200µA	800% @ 200µA	1µs, 30µs	-	DC	Transistor	30V	-	1.2V	5 mA	300mV	-40°C ~ 85°C	Surface Mount
