Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	OutputIsolation	InternalSwitch(s)	Voltage-Breakdown	Topology	Voltage-StartUp	Voltage-Supply(Vcc/Vdd)	DutyCycle	Frequency-Switching	Power(Watts)	FaultProtection	ControlFeatures	OperatingTemperature
NCP1382DR2G IC OFFLINE SWITCH FLYBACK 14SOIC onsemi	2,341	-	RFQ	Datasheet	Tape & Reel (TR),Bulk	-	Obsolete	Isolated	No	-	Flyback	15 V	10V ~ 20V	-	-	-	Over Load, Over Temperature, Over Voltage, Short Circuit	-	0°C ~ 125°C (TJ)
TOP252GN IC OFFLINE SWITCH FLYBACK 8SMD Power Integrations	3,682	-	RFQ	Datasheet	Tube	TOPSwitch®-HX	Discontinued at Mosen	Isolated	Yes	700V	Flyback	-	-	78%	66kHz	15 W	Current Limiting, Over Temperature, Over Voltage	-	-40°C ~ 150°C (TJ)
TOP253GN IC OFFLINE SWITCH FLYBACK 8SMD Power Integrations	2,407	-	RFQ	Datasheet	Tube	TOPSwitch®-HX	Discontinued at Mosen	Isolated	Yes	700V	Flyback	-	-	78%	66kHz	25 W	Current Limiting, Over Temperature, Over Voltage	-	-40°C ~ 150°C (TJ)
TOP252MN IC OFFLINE SW FLYBACK 10CSDIP Power Integrations	2,987	-	RFQ	Datasheet	Tube	TOPSwitch®-HX	Obsolete	Isolated	Yes	700V	Flyback	-	-	78%	66kHz	15 W	Current Limiting, Over Temperature, Over Voltage	-	-40°C ~ 150°C (TJ)
TOP253MN IC OFFLINE SW FLYBACK 10CSDIP Power Integrations	3,716	-	RFQ	Datasheet	Tube	TOPSwitch®-HX	Obsolete	Isolated	Yes	700V	Flyback	-	-	78%	66kHz	25 W	Current Limiting, Over Temperature, Over Voltage	-	-40°C ~ 150°C (TJ)
FSFR1700 IC OFFLINE SW HALF-BRIDGE 9SIP onsemi	3,620	-	RFQ		Tube	FSFR	Obsolete	Isolated	Yes	500V	Half-Bridge	14.5 V	11.3V ~ 25V	50%	Up to 300kHz	200 W	Current Limiting, Over Load, Over Temperature, Over Voltage	EN, Frequency Control	-40°C ~ 130°C (TJ)
FSFR1800 IC OFFLINE SW HALF-BRIDGE 9SIP onsemi	2,949	-	RFQ		Tube	FSFR	Obsolete	Isolated	Yes	500V	Half-Bridge	14.5 V	11.3V ~ 25V	50%	Up to 300kHz	260 W	Current Limiting, Over Load, Over Temperature, Over Voltage	EN, Frequency Control	-40°C ~ 130°C (TJ)
FSFR1900 IC OFFLINE SW HALF-BRIDGE 9SIP onsemi	3,888	-	RFQ		Tube	FSFR	Obsolete	Isolated	Yes	500V	Half-Bridge	14.5 V	11.3V ~ 25V	50%	Up to 300kHz	300 W	Current Limiting, Over Load, Over Temperature, Over Voltage	EN, Frequency Control	-40°C ~ 130°C (TJ)
FSFR2000 IC OFFLINE SW HALF-BRIDGE 9SIP onsemi	2,591	-	RFQ		Tube	FSFR	Obsolete	Isolated	Yes	500V	Half-Bridge	14.5 V	11.3V ~ 25V	50%	Up to 300kHz	350 W	Current Limiting, Over Load, Over Temperature, Over Voltage	EN, Frequency Control	-40°C ~ 130°C (TJ)
LNK603DG IC OFFLINE SWITCH FLYBACK 8SO Power Integrations	3,291	-	RFQ	Datasheet	Tube	LinkSwitch®-II	Discontinued at Mosen	Isolated	Yes	700V	Flyback	-	-	55%	Up to 85kHz	3.3 W	Current Limiting, Open Loop, Over Temperature, Short Circuit	-	-40°C ~ 150°C (TJ)
LNK613DG IC OFFLINE SWITCH FLYBACK 8SO Power Integrations	2,682	-	RFQ	Datasheet	Tube	LinkSwitch®-II	Discontinued at Mosen	Isolated	Yes	700V	Flyback	-	-	55%	Up to 85kHz	3.3 W	Current Limiting, Open Loop, Over Temperature, Short Circuit	-	-40°C ~ 150°C (TJ)
LNK604DG IC OFFLINE SWITCH FLYBACK 8SO Power Integrations	3,537	-	RFQ	Datasheet	Tube	LinkSwitch®-II	Discontinued at Mosen	Isolated	Yes	700V	Flyback	-	-	55%	Up to 85kHz	4.1 W	Current Limiting, Open Loop, Over Temperature, Short Circuit	-	-40°C ~ 150°C (TJ)
LNK614DG IC OFFLINE SWITCH FLYBACK 8SO Power Integrations	3,638	-	RFQ	Datasheet	Tube	LinkSwitch®-II	Discontinued at Mosen	Isolated	Yes	700V	Flyback	-	-	55%	Up to 85kHz	4.1 W	Current Limiting, Open Loop, Over Temperature, Short Circuit	-	-40°C ~ 150°C (TJ)
LNK605DG IC OFFLINE SWITCH FLYBACK 8SO Power Integrations	3,581	-	RFQ	Datasheet	Tube	LinkSwitch®-II	Discontinued at Mosen	Isolated	Yes	700V	Flyback	-	-	55%	Up to 85kHz	5.1 W	Current Limiting, Open Loop, Over Temperature, Short Circuit	-	-40°C ~ 150°C (TJ)
LNK615DG IC OFFLINE SWITCH FLYBACK 8SO Power Integrations	2,992	-	RFQ	Datasheet	Tube	LinkSwitch®-II	Discontinued at Mosen	Isolated	Yes	700V	Flyback	-	-	55%	Up to 85kHz	5.1 W	Current Limiting, Open Loop, Over Temperature, Short Circuit	-	-40°C ~ 150°C (TJ)
LNK606GG IC OFFLINE SWITCH FLYBACK 8SMD Power Integrations	2,216	-	RFQ	Datasheet	Tube	LinkSwitch®-II	Discontinued at Mosen	Isolated	Yes	700V	Flyback	-	-	55%	Up to 85kHz	6.1 W	Current Limiting, Open Loop, Over Temperature, Short Circuit	-	-40°C ~ 150°C (TJ)
LNK616GG IC OFFLINE SWITCH FLYBACK 8SMD Power Integrations	2,105	-	RFQ	Datasheet	Tube	LinkSwitch®-II	Discontinued at Mosen	Isolated	Yes	700V	Flyback	-	-	55%	Up to 85kHz	6.1 W	Current Limiting, Open Loop, Over Temperature, Short Circuit	-	-40°C ~ 150°C (TJ)
FAN6300DZ IC OFFLINE SWITCH FLYBACK 8DIP onsemi	3,876	-	RFQ	Datasheet	Tube	-	Obsolete	Isolated	No	-	Flyback	16 V	8V ~ 25V	-	-	-	Current Limiting, Open Loop, Over Voltage, Short Circuit	-	-40°C ~ 105°C (TA)
FAN6300SZ IC OFFLINE SWITCH FLYBACK 8SOIC onsemi	3,064	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Obsolete	Isolated	No	-	Flyback	16 V	8V ~ 25V	-	-	-	Current Limiting, Open Loop, Over Voltage, Short Circuit	-	-40°C ~ 105°C (TA)
UC2823BN IC OFFLINE SWITCH MULT TOP 16DIP Texas Instruments	3,704	-	RFQ	Datasheet	Tube,Tube	-	Obsolete	Non-Isolated	No	-	Boost, Buck, Flyback, Forward	16 V	10V ~ 22V	100%	1MHz	-	Current Limiting	Frequency Control, Soft Start	-55°C ~ 150°C (TJ)
