Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
IRF3711ZSMOSFET N-CH 20V 92A D2PAK |
3,062 | - |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 92A (Tc) | 4.5V, 10V | 6mOhm @ 15A, 10V | 2.45V @ 250µA | 24 nC @ 4.5 V | ±20V | 2150 pF @ 10 V | - | 79W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
IRF7413ZMOSFET N-CH 30V 13A 8SO |
3,984 | - |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 13A (Ta) | 4.5V, 10V | 10mOhm @ 13A, 10V | 2.25V @ 250µA | 14 nC @ 4.5 V | ±20V | 1210 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
IRF7807ZMOSFET N-CH 30V 11A 8SO |
2,734 | - |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 11A (Ta) | 4.5V, 10V | 13.8mOhm @ 11A, 10V | 2.25V @ 250µA | 11 nC @ 4.5 V | ±20V | 770 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
IRF8113TRMOSFET N-CH 30V 17.2A 8SO |
3,717 | - |
RFQ |
Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 17.2A (Ta) | 4.5V, 10V | 5.6mOhm @ 17.2A, 10V | 2.2V @ 250µA | 36 nC @ 4.5 V | ±20V | 2910 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
IRLR7843TRMOSFET N-CH 30V 161A DPAK |
2,382 | - |
RFQ |
Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 161A (Tc) | 4.5V, 10V | 3.3mOhm @ 15A, 10V | 2.3V @ 250µA | 50 nC @ 4.5 V | ±20V | 4380 pF @ 15 V | - | 140W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
IRF7831TRMOSFET N-CH 30V 21A 8SO |
2,760 | - |
RFQ |
Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 21A (Ta) | 4.5V, 10V | 3.6mOhm @ 20A, 10V | 2.35V @ 250µA | 60 nC @ 4.5 V | ±12V | 6240 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
IRLR7807ZTRMOSFET N-CH 30V 43A DPAK |
2,654 | - |
RFQ |
Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 43A (Tc) | 4.5V, 10V | 13.8mOhm @ 15A, 10V | 2.25V @ 250µA | 11 nC @ 4.5 V | ±20V | 780 pF @ 15 V | - | 40W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
IRLR3714ZTRMOSFET N-CH 20V 37A DPAK |
2,992 | - |
RFQ |
Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 37A (Tc) | 4.5V, 10V | 15mOhm @ 15A, 10V | 2.55V @ 250µA | 7.1 nC @ 4.5 V | ±20V | 560 pF @ 10 V | - | 35W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
IRFR3704ZTRLMOSFET N-CH 20V 60A DPAK |
2,995 | - |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 60A (Tc) | 4.5V, 10V | 8.4mOhm @ 15A, 10V | 2.55V @ 250µA | 14 nC @ 4.5 V | ±20V | 1190 pF @ 10 V | - | 48W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
IRFR3709ZMOSFET N-CH 30V 86A DPAK |
3,999 | - |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 86A (Tc) | 4.5V, 10V | 6.5mOhm @ 15A, 10V | 2.25V @ 250µA | 26 nC @ 4.5 V | ±20V | 2330 pF @ 15 V | - | 79W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
IRL7833SMOSFET N-CH 30V 150A D2PAK |
3,011 | - |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 150A (Tc) | 4.5V, 10V | 3.8mOhm @ 38A, 10V | 2.3V @ 250µA | 47 nC @ 4.5 V | ±20V | 4170 pF @ 15 V | - | 140W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
IRLR3714ZMOSFET N-CH 20V 37A DPAK |
3,057 | - |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 37A (Tc) | 4.5V, 10V | 15mOhm @ 15A, 10V | 2.55V @ 250µA | 7.1 nC @ 4.5 V | ±20V | 560 pF @ 10 V | - | 35W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
IRL3715ZSMOSFET N-CH 20V 50A D2PAK |
2,251 | - |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 50A (Tc) | 4.5V, 10V | 11mOhm @ 15A, 10V | 2.55V @ 250µA | 11 nC @ 4.5 V | ±20V | 870 pF @ 10 V | - | 45W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
IRL3715ZCSMOSFET N-CH 20V 50A D2PAK |
2,087 | - |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 50A (Tc) | 4.5V, 10V | 11mOhm @ 15A, 10V | 2.55V @ 250µA | 11 nC @ 4.5 V | ±20V | 870 pF @ 10 V | - | 45W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
IRL3714ZSMOSFET N-CH 20V 36A D2PAK |
3,679 | - |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 36A (Tc) | 4.5V, 10V | 16mOhm @ 15A, 10V | 2.55V @ 250µA | 7.2 nC @ 4.5 V | ±20V | 550 pF @ 10 V | - | 35W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
IRF8113MOSFET N-CH 30V 17.2A 8SO |
2,136 | - |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 17.2A (Ta) | 4.5V, 10V | 5.6mOhm @ 17.2A, 10V | 2.2V @ 250µA | 36 nC @ 4.5 V | ±20V | 2910 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
64-9145MOSFET N-CH 20V 27A DIRECTFET |
3,644 | - |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 27A (Ta), 150A (Tc) | 4.5V, 10V | 2.7mOhm @ 27A, 10V | 2.45V @ 250µA | 42 nC @ 4.5 V | ±20V | 4130 pF @ 10 V | - | 2.8W (Ta), 89W (Tc) | -40°C ~ 150°C (TJ) | Surface Mount | |
IRF6623MOSFET N-CH 20V 16A DIRECTFET |
3,811 | - |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 16A (Ta), 55A (Tc) | 4.5V, 10V | 5.7mOhm @ 15A, 10V | 2.2V @ 250µA | 17 nC @ 4.5 V | ±20V | 1360 pF @ 10 V | - | 1.4W (Ta), 42W (Tc) | -40°C ~ 150°C (TJ) | Surface Mount | |
IRF3709ZCSMOSFET N-CH 30V 87A D2PAK |
2,121 | - |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 87A (Tc) | 4.5V, 10V | 6.3mOhm @ 21A, 10V | 2.25V @ 250µA | 26 nC @ 4.5 V | ±20V | 2130 pF @ 15 V | - | 79W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
IRF6609MOSFET N-CH 20V 31A DIRECTFET |
3,175 | - |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 31A (Ta), 150A (Tc) | 4.5V, 10V | 2mOhm @ 31A, 10V | 2.45V @ 250µA | 69 nC @ 4.5 V | ±20V | 6290 pF @ 10 V | - | 1.8W (Ta), 89W (Tc) | -40°C ~ 150°C (TJ) | Surface Mount |
