Aluminum Electrolytic Capacitors- Page 14

MAX3232IDR PIC18F25K22T-I/SO 5-160558-2 ESD9B5.0ST5G

Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	Capacitance	Tolerance	Voltage-Rated	ESR(EquivalentSeriesResistance)	Lifetime@Temp	OperatingTemperature	Polarization	Ratings	Applications	RippleCurrent@LowFrequency	RippleCurrent@HighFrequency	Impedance	LeadSpacing	Size/Dimension	Height-Seated(Max)	SurfaceMountLandSize	MountingType
228TTA050M CAP ALUM 2200UF 20% 50V AXIAL Cornell Dubilier / Illinois Capacitor	9,837	-	RFQ	Datasheet	Bulk	TTA	Active	2200 µF	±20%	50 V	120.6mOhm @ 120Hz	2000 Hrs @ 85°C	-40°C ~ 85°C	Polar	-	General Purpose	1.93 A @ 120 Hz	2.4704 A @ 50 kHz	-	-	0.630 Dia x 1.614 L (16.00mm x 41.00mm)	-	-	Through Hole
381LQ331M250H022 CAP ALUM 330UF 20% 250V SNAP Cornell Dubilier Electronics (CDE)	77,245	-	RFQ	Datasheet	Bulk	381LQ	Active	330 µF	±20%	250 V	502mOhm @ 120Hz	2000 Hrs @ 105°C	-40°C ~ 105°C	Polar	-	General Purpose	1.2 A @ 120 Hz	1.68 A @ 20 kHz	-	0.394 (10.00mm)	0.866 Dia (22.00mm)	1.260 (32.00mm)	-	Through Hole
381LQ471M200H022 CAP ALUM 470UF 20% 200V SNAP Cornell Dubilier Electronics (CDE)	8,948	-	RFQ	Datasheet	Bulk	381LQ	Active	470 µF	±20%	200 V	423mOhm @ 120Hz	2000 Hrs @ 105°C	-40°C ~ 105°C	Polar	-	General Purpose	1.45 A @ 120 Hz	2.03 A @ 20 kHz	-	0.394 (10.00mm)	0.866 Dia (22.00mm)	1.260 (32.00mm)	-	Through Hole
380LX472M050H032 CAP ALUM 4700UF 20% 50V SNAP Cornell Dubilier Electronics (CDE)	2,452	-	RFQ	Datasheet	Bulk	380LX	Active	4700 µF	±20%	50 V	110mOhm @ 120Hz	3000 Hrs @ 85°C	-40°C ~ 85°C	Polar	-	General Purpose	3 A @ 120 Hz	3.5 A @ 20 kHz	-	0.394 (10.00mm)	0.866 Dia (22.00mm)	1.457 (37.00mm)	-	Through Hole
LLS2G471MELC CAP ALUM 470UF 20% 400V SNAP Nichicon	2,832	-	RFQ	Datasheet	Bulk	LLS	Active	470 µF	±20%	400 V	-	3000 Hrs @ 85°C	-25°C ~ 85°C	Polar	-	General Purpose	2.51 A @ 120 Hz	3.5893 A @ 50 kHz	-	0.394 (10.00mm)	1.378 Dia (35.00mm)	1.378 (35.00mm)	-	Through Hole
SLPX103M035E3P3 CAP ALUM 10000UF 20% 35V SNAP Cornell Dubilier Electronics (CDE)	13,014	-	RFQ	Datasheet	Bulk	SLPX	Active	10000 µF	±20%	35 V	53mOhm @ 120Hz	3000 Hrs @ 85°C	-40°C ~ 85°C	Polar	-	General Purpose	3.61 A @ 120 Hz	4.51 A @ 20 kHz	-	0.394 (10.00mm)	1.181 Dia (30.00mm)	1.181 (30.00mm)	-	Through Hole
ELXS451VSN331MR40S CAP ALUM 330UF 20% 450V SNAP United Chemi-Con	3,370	-	RFQ	Datasheet	Bulk	LXS	Active	330 µF	±20%	450 V	-	5000 Hrs @ 105°C	-25°C ~ 105°C	Polar	-	General Purpose	1.52 A @ 120 Hz	2.1736 A @ 50 kHz	-	0.394 (10.00mm)	1.181 Dia (30.00mm)	1.654 (42.00mm)	-	Through Hole
MAL213816472E3 CAP ALUM 4700UF 20% 25V AXIAL Vishay Beyschlag/Draloric/BC Components	1,723	-	RFQ	Datasheet	Bulk	138 AML	Active	4700 µF	±20%	25 V	76mOhm @ 100Hz	10000 Hrs @ 105°C	-40°C ~ 105°C	Polar	-	Automotive	1.84 A @ 100 Hz	2.392 A @ 10 kHz	63 mOhms	-	0.709 Dia x 1.496 L (18.00mm x 38.00mm)	-	-	Through Hole
450MXG330MEFCSN35X30 CAP ALUM 330UF 20% 450V SNAP Rubycon	2,611	-	RFQ	Datasheet	Bulk	MXG	Active	330 µF	±20%	450 V	-	3000 Hrs @ 105°C	-25°C ~ 105°C	Polar	-	General Purpose	1.52 A @ 120 Hz	2.128 A @ 10 kHz	-	0.394 (10.00mm)	1.378 Dia (35.00mm)	1.260 (32.00mm)	-	Through Hole
381LX103M035J452 CAP ALUM 10000UF 20% 35V SNAP Cornell Dubilier Electronics (CDE)	11,286	-	RFQ	Datasheet	Bulk	381LX	Active	10000 µF	±20%	35 V	-	3000 Hrs @ 105°C	-40°C ~ 105°C	Polar	-	General Purpose	3.2 A @ 120 Hz	3.7 A @ 20 kHz	-	0.394 (10.00mm)	0.984 Dia (25.00mm)	1.850 (47.00mm)	-	Through Hole
381LX101M450H022 CAP ALUM 100UF 20% 450V SNAP Cornell Dubilier Electronics (CDE)	9,990	-	RFQ	Datasheet	Bulk	381LX	Active	100 µF	±20%	450 V	-	3000 Hrs @ 105°C	-25°C ~ 105°C	Polar	-	General Purpose	-	-	-	0.394 (10.00mm)	0.866 Dia (22.00mm)	1.260 (32.00mm)	-	Through Hole
381LR271M250H022 CAP ALUM 270UF 20% 250V SNAP Cornell Dubilier Electronics (CDE)	12,977	-	RFQ	Datasheet	Bulk	381LR	Active	270 µF	±20%	250 V	737mOhm @ 120Hz	3000 Hrs @ 105°C	-40°C ~ 105°C	Polar	-	General Purpose	1.42 A @ 120 Hz	2.03 A @ 20 kHz	-	0.394 (10.00mm)	0.866 Dia (22.00mm)	1.260 (32.00mm)	-	Through Hole
LGU2G391MELC CAP ALUM 390UF 20% 400V SNAP Nichicon	2,264	-	RFQ	Datasheet	Bulk	LGU	Active	390 µF	±20%	400 V	-	3000 Hrs @ 105°C	-25°C ~ 105°C	Polar	-	General Purpose	1.6 A @ 120 Hz	2.288 A @ 50 kHz	-	0.394 (10.00mm)	1.378 Dia (35.00mm)	1.378 (35.00mm)	-	Through Hole
SLPX222M100C7P3 CAP ALUM 2200UF 20% 100V SNAP Cornell Dubilier Electronics (CDE)	29,118	-	RFQ	Datasheet	Bulk	SLPX	Active	2200 µF	±20%	100 V	121mOhm @ 120Hz	3000 Hrs @ 85°C	-40°C ~ 85°C	Polar	-	General Purpose	3.21 A @ 120 Hz	4.01 A @ 20 kHz	-	0.394 (10.00mm)	0.984 Dia (25.00mm)	1.575 (40.00mm)	-	Through Hole
SLPX223M025E7P3 CAP ALUM 22000UF 20% 25V SNAP Cornell Dubilier Electronics (CDE)	8,691	-	RFQ	Datasheet	Bulk	SLPX	Active	22000 µF	±20%	25 V	27mOhm @ 120Hz	3000 Hrs @ 85°C	-40°C ~ 85°C	Polar	-	General Purpose	5.33 A @ 120 Hz	6.66 A @ 20 kHz	-	0.394 (10.00mm)	1.181 Dia (30.00mm)	1.575 (40.00mm)	-	Through Hole
SLP472M050C5P3 CAP ALUM 4700UF 20% 50V SNAP Cornell Dubilier Electronics (CDE)	27,826	-	RFQ	Datasheet	Bulk	SLP0712TE (750W)	Active	4700 µF	±20%	50 V	99mOhm	3000 Hrs @ 105°C	-40°C ~ 105°C	-	-	General Purpose	-	-	-	0.394 (10.00mm)	0.984 Dia (25.00mm)	1.378 (35.00mm)	-	Through Hole
ESMQ451VSN561MR50S CAP ALUM 560UF 20% 450V SNAP United Chemi-Con	1,869	-	RFQ	Datasheet	Bulk	SMQ	Active	560 µF	±20%	450 V	-	2000 Hrs @ 85°C	-25°C ~ 85°C	Polar	-	General Purpose	2.82 A @ 120 Hz	4.033 A @ 50 kHz	-	0.394 (10.00mm)	1.181 Dia (30.00mm)	1.969 (50.00mm)	-	Through Hole
MAL214699814E3 CAP ALUM 1000UF 20% 63V SMD Vishay Beyschlag/Draloric/BC Components	9,163	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	146 CTI	Active	1000 µF	±20%	63 V	-	6000 Hrs @ 125°C	-55°C ~ 125°C	Polar	AEC-Q200	Automotive	840 mA @ 100 Hz	1.4 A @ 100 kHz	72 mOhms	-	0.709 Dia (18.00mm)	0.866 (22.00mm)	0.709 L x 0.709 W (18.00mm x 18.00mm)	Surface Mount
380LX221M400K022 CAP ALUM 220UF 20% 400V SNAP Cornell Dubilier Electronics (CDE)	3,585	-	RFQ	Datasheet	Bulk	380LX	Active	220 µF	±20%	400 V	750mOhm @ 120Hz	3000 Hrs @ 85°C	-25°C ~ 85°C	Polar	-	General Purpose	1.5 A @ 120 Hz	2.1 A @ 20 kHz	-	0.394 (10.00mm)	1.181 Dia (30.00mm)	1.260 (32.00mm)	-	Through Hole
SLPX222M100E3P3 CAP ALUM 2200UF 20% 100V SNAP Cornell Dubilier Electronics (CDE)	482	-	RFQ	Datasheet	Bulk	SLPX	Active	2200 µF	±20%	100 V	121mOhm @ 120Hz	3000 Hrs @ 85°C	-40°C ~ 85°C	Polar	-	General Purpose	3.17 A @ 120 Hz	3.96 A @ 20 kHz	-	0.394 (10.00mm)	1.181 Dia (30.00mm)	1.181 (30.00mm)	-	Through Hole
