Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	IGBTType	Configuration	Voltage-CollectorEmitterBreakdown(Max)	Current-Collector(Ic)(Max)	Power-Max	Vce(on)(Max)@VgeIc	Current-CollectorCutoff(Max)	InputCapacitance(Cies)@Vce	Input	NTCThermistor	OperatingTemperature	MountingType
APTGF50SK120T1G IGBT MODULE 1200V 75A 312W SP1 Microsemi Corporation	2,416	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF50SK120TG IGBT MODULE 1200V 75A 312W SP4 Microsemi Corporation	3,106	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Single	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF50TA120PG IGBT MODULE 1200V 75A 312W SP6P Microsemi Corporation	2,280	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Three Phase	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF50TDU120PG IGBT MODULE 1200V 75A 312W SP6P Microsemi Corporation	2,083	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Triple, Dual - Common Source	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF50X60T3G IGBT MODULE 600V 65A 250W SP3 Microsemi Corporation	3,573	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Three Phase Inverter	600 V	65 A	250 W	2.45V @ 15V, 50A	250 µA	2.2 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF530U120D4G IGBT MODULE 1200V 700A 3900W D4 Microsemi Corporation	3,619	-	RFQ		Bulk	-	Obsolete	NPT	Single	1200 V	700 A	3900 W	3.7V @ 15V, 600A	5 mA	37 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF660U60D4G IGBT MODULE 600V 860A 2800W D4 Microsemi Corporation	3,374	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	600 V	860 A	2800 W	2.45V @ 15V, 800A	500 µA	36 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF75DA120T1G IGBT MODULE 1200V 100A 500W SP1 Microsemi Corporation	2,013	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	1200 V	100 A	500 W	3.7V @ 15V, 75A	250 µA	5.1 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF75DA60D1G IGBT MODULE 600V 100A 355W D1 Microsemi Corporation	3,945	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Single	600 V	100 A	355 W	2.45V @ 15V, 75A	500 µA	3.3 nF @ 25 V	Standard	No	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF75DDA120TG IGBT MODULE 1200V 100A 500W SP4 Microsemi Corporation	3,683	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Dual, Common Source	1200 V	100 A	500 W	3.7V @ 15V, 75A	250 µA	5.1 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF75DH120TG IGBT MODULE 1200V 100A 500W SP4 Microsemi Corporation	2,581	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Asymmetrical Bridge	1200 V	100 A	500 W	3.7V @ 15V, 75A	250 µA	5.1 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF75DSK120TG IGBT MODULE 1200V 100A 500W SP4 Microchip Technology	3,858	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Dual, Common Source	1200 V	100 A	500 W	3.7V @ 15V, 75A	250 µA	5.1 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF75H120TG IGBT MODULE 1200V 100A 500W SP4 Microchip Technology	3,545	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Full Bridge Inverter	1200 V	100 A	500 W	3.7V @ 15V, 75A	250 µA	5.1 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF75SK60D1G IGBT MODULE 600V 100A 355W D1 Microsemi Corporation	2,151	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Single	600 V	100 A	355 W	2.45V @ 15V, 75A	500 µA	3.3 nF @ 25 V	Standard	No	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF90A60D1G IGBT MODULE NPT PHASE LEG D1 Microsemi Corporation	2,121	-	RFQ		Bulk	-	Discontinued at Mosen	NPT	Half Bridge	-	-	-	-	-	-	Standard	No	-	Chassis Mount
APTGF90A60T1G IGBT MODULE 600V 110A 416W SP1 Microchip Technology	2,151	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Half Bridge	600 V	110 A	416 W	2.5V @ 15V, 90A	250 µA	4.3 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF90A60TG IGBT MODULE 600V 110A 416W SP4 Microchip Technology	2,391	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Half Bridge	600 V	110 A	416 W	2.5V @ 15V, 90A	250 µA	4.3 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF90DA60D1G IGBT MODULE 600V 130A 445W D1 Microsemi Corporation	3,504	-	RFQ		Bulk	-	Discontinued at Mosen	NPT	Single	600 V	130 A	445 W	2.45V @ 15V, 100A	500 µA	4.3 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF90DA60T1G IGBT MODULE 600V 110A 416W SP1 Microsemi Corporation	2,348	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	600 V	110 A	416 W	2.5V @ 15V, 90A	250 µA	4.3 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF90DA60TG IGBT MODULE 600V 110A 416W SP4 Microsemi Corporation	3,226	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Single	600 V	110 A	416 W	2.5V @ 15V, 90A	250 µA	4.3 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
