Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	IGBTType	Configuration	Voltage-CollectorEmitterBreakdown(Max)	Current-Collector(Ic)(Max)	Power-Max	Vce(on)(Max)@VgeIc	Current-CollectorCutoff(Max)	InputCapacitance(Cies)@Vce	Input	NTCThermistor	OperatingTemperature	MountingType
FS35R12KE3GBOSA1 IGBT MOD 1200V 55A 200W Infineon Technologies	3,965	-	RFQ	Datasheet	Tray	-	Discontinued at Mosen	-	Full Bridge	1200 V	55 A	200 W	2.15V @ 15V, 35A	5 mA	2.5 nF @ 25 V	Standard	Yes	-40°C ~ 125°C	Chassis Mount
FS35R12KT3BOSA1 IGBT MOD 1200V 55A 210W Infineon Technologies	3,805	-	RFQ	Datasheet	Tray	EconoPACK™ 2	Discontinued at Mosen	-	Full Bridge Inverter	1200 V	55 A	210 W	2.15V @ 15V, 35A	5 mA	2.5 nF @ 25 V	Standard	Yes	-40°C ~ 125°C	Chassis Mount
FS35R12U1T4BPSA1 IGBT MOD 1200V 70A 250W Infineon Technologies	3,128	-	RFQ	Datasheet	Tray	SmartPACK1	Obsolete	Trench Field Stop	Full Bridge	1200 V	70 A	250 W	2.25V @ 15V, 35A	1 mA	2 nF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FS400R12A2T4IBPSA1 IGBT MOD 1200V 400A 1500W Infineon Technologies	2,228	-	RFQ		Tray	HybridPACK™ 2	Obsolete	Trench Field Stop	Full Bridge	1200 V	400 A	1500 W	1.85V @ 15V, 300A	1 mA	25 nF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FS50R06KE3BOSA1 IGBT MODULE 600V 70A 190W Infineon Technologies	3,754	-	RFQ	Datasheet	Tray	EconoPACK™ 3	Discontinued at Mosen	Trench Field Stop	Three Phase Inverter	600 V	70 A	190 W	1.9V @ 15V, 50A	1 mA	3.1 nF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FS50R06YL4BOMA1 IGBT MODULE 600V 55A 202W Infineon Technologies	2,085	-	RFQ		Tray	-	Obsolete	-	Three Phase Inverter	600 V	55 A	202 W	2.55V @ 15V, 50A	5 mA	200 pF @ 25 V	Standard	Yes	-40°C ~ 125°C	Chassis Mount
FS50R07N2E4B11BOSA1 IGBT MODULE 650V 70A 190W Infineon Technologies	3,271	-	RFQ	Datasheet	Tray,Tray	EconoPACK™ 2	Obsolete	Trench Field Stop	Three Phase Inverter	650 V	70 A	190 W	1.95V @ 15V, 50A	1 mA	3.1 nF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FS50R07N2E4BOSA1 IGBT MODULE 650V 70A 190W Infineon Technologies	3,162	-	RFQ	Datasheet	Tray	EconoPACK™ 2	Obsolete	-	Full Bridge Inverter	650 V	70 A	190 W	1.95V @ 15V, 50A	1 mA	3.1 nF @ 25 V	Standard	Yes	-40°C ~ 125°C	Chassis Mount
FS50R07U1E4BPSA1 IGBT MODULE 650V 75A 230W Infineon Technologies	3,557	-	RFQ	Datasheet	Tray	SmartPACK1	Obsolete	Trench Field Stop	Full Bridge Inverter	650 V	75 A	230 W	1.95V @ 15V, 50A	1 mA	95 pF @ 25 V	Standard	Yes	-40°C ~ 125°C	Chassis Mount
FS50R12KT4B11BOSA1 IGBT MOD 1200V 50A 280W Infineon Technologies	101	-	RFQ	Datasheet	Bulk,Tray	EconoPACK™ 2	Discontinued at Mosen	Trench Field Stop	Full Bridge	1200 V	50 A	280 W	2.15V @ 15V, 50A	1 mA	2.8 nF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FS50R12KT4B15BOSA1 IGBT MOD 1200V 50A 280W Infineon Technologies	2,921	-	RFQ	Datasheet	Bulk	EconoPACK™ 2	Discontinued at Mosen	Trench Field Stop	Three Phase Inverter	1200 V	50 A	280 W	2.15V @ 15V, 50A	1 mA	2.8 nF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FS50R12U1T4BPSA1 IGBT MOD 1200V 90A 250W Infineon Technologies	2,299	-	RFQ	Datasheet	Tray	SmartPACK1	Obsolete	Trench Field Stop	Three Phase Inverter	1200 V	90 A	250 W	2.15V @ 15V, 50A	1 mA	100 pF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FS50R17KE3B17BOSA1 IGBT MOD 1700V 82A 345W Infineon Technologies	2,822	-	RFQ	Datasheet	Tray	EconoPACK™ 2	Discontinued at Mosen	Trench Field Stop	Full Bridge	1700 V	82 A	345 W	2.45V @ 15V, 50A	1 mA	4.5 nF @ 25 V	Standard	No	-40°C ~ 125°C	Chassis Mount
FS6R06VE3B2BOMA1 IGBT MOD 600V 11A 40.5W Infineon Technologies	3,213	-	RFQ	Datasheet	Tray	-	Obsolete	-	Full Bridge	600 V	11 A	40.5 W	2V @ 15V, 6A	1 mA	330 pF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FS75R06KE3BOSA1 IGBT MODULE 600V 75A 250W Infineon Technologies	3,600	-	RFQ	Datasheet	Tray	EconoPACK™	Discontinued at Mosen	Trench Field Stop	Half Bridge	600 V	75 A	250 W	1.9V @ 15V, 75A	1 mA	4.6 nF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FS75R07N2E4B11BOSA1 IGBT MODULE 650V 75A 250W Infineon Technologies	2,362	-	RFQ	Datasheet	Bulk,Tray	EconoPACK™ 2	Discontinued at Mosen	Trench Field Stop	Three Phase Inverter	650 V	75 A	250 W	1.95V @ 15V, 75A	1 mA	4.6 nF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FS75R07N2E4BOSA1 IGBT MODULE 650V 75A 250W Infineon Technologies	3,007	-	RFQ	Datasheet	Tray	EconoPACK™ 2	Discontinued at Mosen	Trench Field Stop	Three Phase Inverter	650 V	75 A	250 W	1.95V @ 15V, 75A	1 mA	4.6 nF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FS75R12KE3B9BOSA1 IGBT MOD 1200V 105A 355W Infineon Technologies	2,272	-	RFQ	Datasheet	Bulk,Tray	-	Discontinued at Mosen	Trench Field Stop	Three Phase Inverter	1200 V	105 A	355 W	2.15V @ 15V, 75A	1 mA	5.3 nF @ 25 V	Standard	No	-40°C ~ 125°C	Chassis Mount
FS75R12KT4B11BOSA1 IGBT MOD 1200V 75A 385W Infineon Technologies	3,951	-	RFQ	Datasheet	Bulk,Tray	EconoPACK™ 2	Discontinued at Mosen	Trench Field Stop	Three Phase Inverter	1200 V	75 A	385 W	2.15V @ 15V, 75A	1 mA	4.3 nF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FS800R07A2E3IB31BPSA1 IGBT MODULE MED PWR ECOHY2-1 Infineon Technologies	2,734	-	RFQ		Tray	HybridPACK™ 2	Obsolete	-	-	-	-	-	-	-	-	-	-	-	-
