Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	IGBTType	Configuration	Voltage-CollectorEmitterBreakdown(Max)	Current-Collector(Ic)(Max)	Power-Max	Vce(on)(Max)@VgeIc	Current-CollectorCutoff(Max)	InputCapacitance(Cies)@Vce	Input	NTCThermistor	OperatingTemperature	MountingType
BSM50GP60GBOSA1 IGBT MODULE 600V 70A 250W Infineon Technologies	2,995	-	RFQ		Bulk,Tray	-	Obsolete	-	Three Phase Inverter	600 V	70 A	250 W	2.55V @ 15V, 50A	500 µA	2.8 nF @ 25 V	Three Phase Bridge Rectifier	Yes	-40°C ~ 125°C	Chassis Mount
BSM75GAL120DN2HOSA1 IGBT MOD 1200V 105A 625W Infineon Technologies	3,586	-	RFQ		Bulk,Tray	-	Obsolete	-	Single Switch	1200 V	105 A	625 W	3V @ 15V, 75A	1.4 mA	5.5 nF @ 25 V	Standard	No	150°C (TJ)	Chassis Mount
BSM75GAR120DN2HOSA1 IGBT MOD 1200V 30A 235W Infineon Technologies	3,575	-	RFQ		Bulk,Tray	-	Obsolete	Trench Field Stop	Single	1200 V	30 A	235 W	2.2V @ 15V, 15A	400 µA	1 nF @ 25 V	Standard	No	-40°C ~ 175°C (TJ)	Chassis Mount
BSM75GB120DLCHOSA1 IGBT MOD 1200V 170A 690W Infineon Technologies	2,226	-	RFQ		Bulk,Tray	-	Obsolete	-	2 Independent	1200 V	170 A	690 W	2.6V @ 15V, 75A	5 mA	5.1 nF @ 25 V	Standard	No	-40°C ~ 125°C	Chassis Mount
BSM75GB120DN2HOSA1 IGBT MOD 1200V 105A 625W Infineon Technologies	2,941	-	RFQ		Tray	-	Obsolete	-	Half Bridge	1200 V	105 A	625 W	3V @ 15V, 75A	1.5 mA	5.5 nF @ 25 V	Standard	No	150°C (TJ)	Chassis Mount
BSM75GD60DLCBOSA1 IGBT MODULE 600V 95A 330W Infineon Technologies	3,949	-	RFQ		Tray	-	Obsolete	-	Full Bridge	600 V	95 A	330 W	2.45V @ 15V, 75A	500 µA	3.3 nF @ 25 V	Standard	No	-40°C ~ 125°C	Chassis Mount
BSM75GP60BOSA1 IGBT MOD 600V 100A 310W Infineon Technologies	2,921	-	RFQ		Tray	-	Obsolete	-	Three Phase Inverter	600 V	100 A	310 W	2.45V @ 15V, 75A	500 µA	3.3 nF @ 25 V	Three Phase Bridge Rectifier	Yes	-40°C ~ 125°C	Chassis Mount
BYM300B170DN2HOSA1 IGBT MOD 650V 40A 20MW Infineon Technologies	2,107	-	RFQ	Datasheet	Bulk,Tray	-	Obsolete	Trench Field Stop	2 Independent	650 V	40 A	20 mW	1.55V @ 15V, 25A	40 µA	2.8 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
BYM600A170DN2HOSA1 IGBT MODULE 1400W MED PWR 62MM-2 Infineon Technologies	2,758	-	RFQ	Datasheet	Bulk,Tray	-	Obsolete	-	Single	-	-	1400 W	-	-	-	Standard	No	150°C (TJ)	Chassis Mount
DDB6U100N16RRBOSA1 IGBT MOD 1200V 50A 350W Infineon Technologies	3,027	-	RFQ	Datasheet	Bulk,Tray	-	Discontinued at Mosen	-	Single Chopper	1200 V	50 A	350 W	3.2V @ 20V, 50A	1 mA	3.3 nF @ 25 V	Standard	No	-40°C ~ 150°C	Chassis Mount
F4100R06KL4BOSA1 IGBT MOD 600V 130A 430W Infineon Technologies	2,860	-	RFQ		Tray	-	Obsolete	-	Half Bridge	600 V	130 A	430 W	2.55V @ 15V, 100A	5 mA	4.3 nF @ 25 V	Standard	Yes	-40°C ~ 125°C	Chassis Mount
F4100R17ME4B11BPSA1 IGBT MODULE 1700V 155A Infineon Technologies	2,759	-	RFQ	Datasheet	Bulk,Tray	EconoDUAL™ 3	Discontinued at Mosen	Trench Field Stop	Full Bridge	1700 V	155 A	-	2.3V @ 15V, 100A	3 mA	9 nF @ 25 V	Standard	No	-40°C ~ 150°C	Chassis Mount
F4150R06KL4BOSA1 IGBT MOD 600V 180A 570W Infineon Technologies	3,218	-	RFQ		Tray	-	Obsolete	-	Full Bridge	600 V	180 A	570 W	2.55V @ 15V, 150A	5 mA	6.5 nF @ 25 V	Standard	Yes	-40°C ~ 125°C	Chassis Mount
F4150R17ME4B11BPSA1 IGBT MODULE 1700V 230A Infineon Technologies	3,511	-	RFQ	Datasheet	Tray	EconoDUAL™ 3	Discontinued at Mosen	Trench Field Stop	Full Bridge	1700 V	230 A	-	2.3V @ 15V, 150A	3 mA	12 nF @ 25 V	Standard	No	-40°C ~ 150°C	Chassis Mount
F4200R06KL4BOSA1 IGBT MOD 600V 225A 695W Infineon Technologies	3,903	-	RFQ		Tray	-	Obsolete	-	Full Bridge	600 V	225 A	695 W	2.55V @ 15V, 200A	5 mA	9 nF @ 25 V	Standard	No	-40°C ~ 125°C	Chassis Mount
F4250R17MP4B11BPSA1 IGBT MODULE 1700V 370A Infineon Technologies	462	-	RFQ	Datasheet	Bulk,Tray	EconoDUAL™ 3	Discontinued at Mosen	Trench Field Stop	Full Bridge Inverter	1700 V	370 A	-	2.3V @ 15V, 250A	3 mA	21 nF @ 25 V	Standard	No	-40°C ~ 150°C	Chassis Mount
F575R06KE3B5BOSA1 IGBT MODULE 600V 75A 250W Infineon Technologies	2,980	-	RFQ	Datasheet	Tray	EconoPACK™ 3	Obsolete	Trench Field Stop	Three Phase Inverter	600 V	75 A	250 W	1.9V @ 15V, 75A	1 mA	4.6 nF @ 25 V	Standard	Yes	-40°C ~ 150°C	Chassis Mount
FB10R06KL4BOMA1 MOD IGBT LOW PWR EASY1-1 Infineon Technologies	760	-	RFQ		Bulk,Tray	-	Obsolete	-	-	-	-	-	-	-	-	-	-	-	-
FB10R06KL4GB1BOMA1 MOD IGBT LOW PWR EASY2-1 Infineon Technologies	3,192	-	RFQ		Tray	-	Obsolete	-	-	-	-	-	-	-	-	-	-	-	-
FB10R06KL4GBOMA1 MOD IGBT LOW PWR EASY2-1 Infineon Technologies	3,021	-	RFQ		Tray	-	Obsolete	-	-	-	-	-	-	-	-	-	-	-	-
