Transistors - IGBTs - Modules- Page 170

MAX3232IDR AOZ5311NQI-03 5-160558-2 ESD9B5.0ST5G

Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	IGBTType	Configuration	Voltage-CollectorEmitterBreakdown(Max)	Current-Collector(Ic)(Max)	Power-Max	Vce(on)(Max)@VgeIc	Current-CollectorCutoff(Max)	InputCapacitance(Cies)@Vce	Input	NTCThermistor	OperatingTemperature	MountingType
APTGF50H120TG IGBT MODULE 1200V 75A 312W SP4 Microsemi Corporation	2,588	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Full Bridge Inverter	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF50SK120T1G IGBT MODULE 1200V 75A 312W SP1 Microsemi Corporation	3,023	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF50SK120TG IGBT MODULE 1200V 75A 312W SP4 Microsemi Corporation	2,605	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Single	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF50TA120PG IGBT MODULE 1200V 75A 312W SP6P Microsemi Corporation	3,956	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Three Phase	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF50TDU120PG IGBT MODULE 1200V 75A 312W SP6P Microsemi Corporation	3,964	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Triple, Dual - Common Source	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF50X60T3G IGBT MODULE 600V 65A 250W SP3 Microsemi Corporation	3,955	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Three Phase Inverter	600 V	65 A	250 W	2.45V @ 15V, 50A	250 µA	2.2 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF530U120D4G IGBT MODULE 1200V 700A 3900W D4 Microsemi Corporation	3,879	-	RFQ		Bulk	-	Obsolete	NPT	Single	1200 V	700 A	3900 W	3.7V @ 15V, 600A	5 mA	37 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF660U60D4G IGBT MODULE 600V 860A 2800W D4 Microsemi Corporation	3,533	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	600 V	860 A	2800 W	2.45V @ 15V, 800A	500 µA	36 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF75DA120T1G IGBT MODULE 1200V 100A 500W SP1 Microsemi Corporation	2,029	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	1200 V	100 A	500 W	3.7V @ 15V, 75A	250 µA	5.1 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF75DA60D1G IGBT MODULE 600V 100A 355W D1 Microsemi Corporation	3,543	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Single	600 V	100 A	355 W	2.45V @ 15V, 75A	500 µA	3.3 nF @ 25 V	Standard	No	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF75DDA120TG IGBT MODULE 1200V 100A 500W SP4 Microsemi Corporation	3,627	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Dual, Common Source	1200 V	100 A	500 W	3.7V @ 15V, 75A	250 µA	5.1 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF75DH120TG IGBT MODULE 1200V 100A 500W SP4 Microsemi Corporation	3,508	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Asymmetrical Bridge	1200 V	100 A	500 W	3.7V @ 15V, 75A	250 µA	5.1 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF75SK60D1G IGBT MODULE 600V 100A 355W D1 Microsemi Corporation	3,904	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Single	600 V	100 A	355 W	2.45V @ 15V, 75A	500 µA	3.3 nF @ 25 V	Standard	No	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF90A60D1G IGBT MODULE NPT PHASE LEG D1 Microsemi Corporation	3,190	-	RFQ		Bulk	-	Discontinued at Mosen	NPT	Half Bridge	-	-	-	-	-	-	Standard	No	-	Chassis Mount
APTGF90DA60D1G IGBT MODULE 600V 130A 445W D1 Microsemi Corporation	3,405	-	RFQ		Bulk	-	Discontinued at Mosen	NPT	Single	600 V	130 A	445 W	2.45V @ 15V, 100A	500 µA	4.3 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF90DA60T1G IGBT MODULE 600V 110A 416W SP1 Microsemi Corporation	2,151	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	600 V	110 A	416 W	2.5V @ 15V, 90A	250 µA	4.3 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF90DA60TG IGBT MODULE 600V 110A 416W SP4 Microsemi Corporation	2,542	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Single	600 V	110 A	416 W	2.5V @ 15V, 90A	250 µA	4.3 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF90DH60TG IGBT MODULE 600V 110A 416W SP4 Microsemi Corporation	2,254	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Asymmetrical Bridge	600 V	110 A	416 W	2.5V @ 15V, 90A	250 µA	4.3 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF90DU60TG IGBT MODULE 600V 110A 416W SP4 Microsemi Corporation	3,645	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Dual, Common Source	600 V	110 A	416 W	2.5V @ 15V, 90A	250 µA	4.3 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF90H60TG IGBT MODULE 600V 110A 416W SP4 Microsemi Corporation	3,462	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Full Bridge Inverter	600 V	110 A	416 W	2.5V @ 15V, 90A	250 µA	4.3 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
