Transistors - IGBTs - Modules- Page 169

MAX3232IDR AOZ5311NQI-03 5-160558-2 ESD9B5.0ST5G

Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	IGBTType	Configuration	Voltage-CollectorEmitterBreakdown(Max)	Current-Collector(Ic)(Max)	Power-Max	Vce(on)(Max)@VgeIc	Current-CollectorCutoff(Max)	InputCapacitance(Cies)@Vce	Input	NTCThermistor	OperatingTemperature	MountingType
APTGF300SK120D3G IGBT MODULE 1200V 420A 2100W D3 Microsemi Corporation	2,911	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	1200 V	420 A	2100 W	3.7V @ 15V, 300A	5 mA	19 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF30A60T1G IGBT MODULE 600V 42A 140W SP1 Microsemi Corporation	2,835	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Half Bridge	600 V	42 A	140 W	2.45V @ 15V, 30A	250 µA	1.35 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF30X60T3G IGBT MODULE 600V 42A 140W SP3 Microsemi Corporation	2,246	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Three Phase Inverter	600 V	42 A	140 W	2.45V @ 15V, 30A	250 µA	1.35 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF330A60D3G IGBT MODULE 600V 520A 1560W D3 Microsemi Corporation	3,857	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Half Bridge	600 V	520 A	1560 W	2.45V @ 15V, 400A	500 µA	18 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF330DA60D3G IGBT MODULE 600V 460A 1400W D3 Microsemi Corporation	2,545	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	600 V	460 A	1400 W	2.5V @ 15V, 400A	750 µA	18 nF @ 25 V	Standard	No	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF330SK60D3G IGBT MODULE 600V 460A 1400W D3 Microsemi Corporation	3,155	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	600 V	460 A	1400 W	2.5V @ 15V, 400A	750 µA	18 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF350DA60G IGBT MODULE 600V 430A 1562W SP6 Microsemi Corporation	3,238	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	600 V	430 A	1562 W	2.5V @ 15V, 360A	200 µA	17.2 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF350DU60G IGBT MODULE 600V 430A 1562W SP6 Microsemi Corporation	3,767	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Dual, Common Source	600 V	430 A	1562 W	2.5V @ 15V, 360A	200 µA	17.2 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF350SK60G IGBT MODULE 600V 430A 1562W SP6 Microsemi Corporation	3,121	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	600 V	430 A	1562 W	2.5V @ 15V, 360A	200 µA	17.2 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF360U60D4G IGBT MODULE 600V 450A 1560W D4 Microsemi Corporation	2,306	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	600 V	450 A	1560 W	2.45V @ 15V, 360A	500 µA	17 nF @ 25 V	Standard	No	-	Chassis Mount
APTGF400U120D4G IGBT MODULE 1200V 510A 2500W D4 Microsemi Corporation	2,165	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	1200 V	510 A	2500 W	3.7V @ 15V, 400A	5 mA	26 nF @ 25 V	Standard	No	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF50A120T1G IGBT MODULE 1200V 75A 312W SP1 Microsemi Corporation	3,037	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Half Bridge	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF50A120TG IGBT MODULE 1200V 75A 312W SP4 Microsemi Corporation	3,468	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Half Bridge	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF50A60T1G IGBT MODULE 600V 65A 250W SP1 Microsemi Corporation	2,226	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Half Bridge	600 V	65 A	250 W	2.45V @ 15V, 50A	250 µA	2.2 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF50DA120T1G IGBT MODULE 1200V 75A 312W SP1 Microsemi Corporation	2,728	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Single	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF50DA120TG IGBT MODULE 1200V 75A 312W SP4 Microsemi Corporation	2,963	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Single	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF50DH120TG IGBT MODULE 1200V 75A 312W SP4 Microsemi Corporation	2,259	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Asymmetrical Bridge	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF50DH60TG IGBT MODULE 600V 65A 250W SP4 Microsemi Corporation	3,407	-	RFQ	Datasheet	Bulk	-	Discontinued at Mosen	NPT	Asymmetrical Bridge	600 V	65 A	250 W	2.45V @ 15V, 50A	250 µA	2.2 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
APTGF50DSK60T3G IGBT MODULE 600V 65A 250W SP3 Microsemi Corporation	2,259	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Dual Buck Chopper	600 V	65 A	250 W	2.45V @ 15V, 50A	250 µA	2.2 nF @ 25 V	Standard	Yes	-	Chassis Mount
APTGF50DU120TG IGBT MODULE 1200V 75A 312W SP4 Microsemi Corporation	3,073	-	RFQ	Datasheet	Bulk	-	Obsolete	NPT	Dual, Common Source	1200 V	75 A	312 W	3.7V @ 15V, 50A	250 µA	3.45 nF @ 25 V	Standard	Yes	-40°C ~ 150°C (TJ)	Chassis Mount
