Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	Capacitance	Tolerance	Voltage-Rated	ESR(EquivalentSeriesResistance)	Lifetime@Temp	OperatingTemperature	Polarization	Ratings	Applications	RippleCurrent@LowFrequency	RippleCurrent@HighFrequency	Impedance	LeadSpacing	Size/Dimension	Height-Seated(Max)	SurfaceMountLandSize	MountingType
865080542006 CAP ALUM 22UF 20% 35V SMD Würth Elektronik	15,202	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	WCAP-ASLI	Active	22 µF	±20%	35 V	-	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	-	General Purpose	100.75 mA @ 120 Hz	155 mA @ 100 kHz	1.1 Ohms	-	0.197 Dia (5.00mm)	0.217 (5.50mm)	0.209 L x 0.209 W (5.30mm x 5.30mm)	Surface Mount
865080142007 CAP ALUM 100UF 20% 6.3V SMD Würth Elektronik	5,108	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	WCAP-ASLI	Active	100 µF	±20%	6.3 V	-	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	-	General Purpose	110.5 mA @ 120 Hz	170 mA @ 100 kHz	800 mOhms	-	0.197 Dia (5.00mm)	0.217 (5.50mm)	0.209 L x 0.209 W (5.30mm x 5.30mm)	Surface Mount
EEU-FM1E101B CAP ALUM 100UF 20% 25V RADIAL Panasonic Electronic Components	2,363	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	FM-A	Active	100 µF	±20%	25 V	-	2000 Hrs @ 105°C	-40°C ~ 105°C	Polar	-	General Purpose	318.5 mA @ 120 Hz	455 mA @ 100 kHz	130 mOhms	0.197 (5.00mm)	0.248 Dia (6.30mm)	0.500 (12.70mm)	-	Through Hole
63YXF100MEFCT810X12.5 CAP ALUM 100UF 20% 63V RADIAL Rubycon	18,002	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	YXF	Active	100 µF	±20%	63 V	-	7000 Hrs @ 105°C	-40°C ~ 105°C	Polar	-	General Purpose	210 mA @ 120 Hz	300 mA @ 100 kHz	430 mOhms	0.197 (5.00mm)	0.394 Dia (10.00mm)	0.551 (14.00mm)	-	Through Hole
EEU-FC1V560H CAP ALUM 56UF 20% 35V RADIAL Panasonic Electronic Components	6,935	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	FC	Active	56 µF	±20%	35 V	-	1000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive	188.5 mA @ 120 Hz	290 mA @ 100 kHz	350 mOhms	0.098 (2.50mm)	0.248 Dia (6.30mm)	0.480 (12.20mm)	-	Through Hole
EEE-HAA330WAR CAP ALUM 33UF 20% 10V SMD Panasonic Electronic Components	256,487	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	HA	Active	33 µF	±20%	10 V	-	1000 Hrs @ 105°C	-40°C ~ 105°C	Polar	AEC-Q200	Automotive	29 mA @ 120 Hz	49.3 mA @ 10 kHz	-	-	0.157 Dia (4.00mm)	0.213 (5.40mm)	0.169 L x 0.169 W (4.30mm x 4.30mm)	Surface Mount
EEE-HAE100WAR CAP ALUM 10UF 20% 25V SMD Panasonic Electronic Components	129,726	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	HA	Active	10 µF	±20%	25 V	-	1000 Hrs @ 105°C	-40°C ~ 105°C	Polar	AEC-Q200	Automotive	22 mA @ 120 Hz	37.4 mA @ 10 kHz	-	-	0.157 Dia (4.00mm)	0.213 (5.40mm)	0.169 L x 0.169 W (4.30mm x 4.30mm)	Surface Mount
860020273011 CAP ALUM 470UF 20% 10V RADIAL Würth Elektronik	16,402	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	WCAP-ATG5	Active	470 µF	±20%	10 V	-	2000 Hrs @ 105°C	-40°C ~ 105°C	Polar	-	General Purpose	235 mA @ 120 Hz	324.3 mA @ 100 kHz	-	0.098 (2.50mm)	0.248 Dia (6.30mm)	0.492 (12.50mm)	-	Through Hole
865060342002 CAP ALUM 22UF 20% 16V SMD Würth Elektronik	2,960	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	WCAP-ASLL	Active	22 µF	±20%	16 V	-	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	-	General Purpose	97.5 mA @ 120 Hz	150 mA @ 100 kHz	800 mOhms	-	0.197 Dia (5.00mm)	0.217 (5.50mm)	0.209 L x 0.209 W (5.30mm x 5.30mm)	Surface Mount
EEU-FR1V680B CAP ALUM 68UF 20% 35V RADIAL Panasonic Electronic Components	2,169	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	FR-A	Active	68 µF	±20%	35 V	-	5000 Hrs @ 105°C	-40°C ~ 105°C	Polar	-	General Purpose	318.5 mA @ 120 Hz	455 mA @ 100 kHz	130 mOhms	0.197 (5.00mm)	0.248 Dia (6.30mm)	0.500 (12.70mm)	-	Through Hole
EMZA500ADA220MF61G CAP ALUM 22UF 20% 50V SMD United Chemi-Con	2,949	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	Alchip™- MZA	Active	22 µF	±20%	50 V	-	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive	66 mA @ 120 Hz	165 mA @ 100 kHz	880 mOhms	-	0.248 Dia (6.30mm)	0.240 (6.10mm)	0.260 L x 0.260 W (6.60mm x 6.60mm)	Surface Mount
EEV106M025A9BAA CAP ALUM 10UF 20% 25V SMD KEMET	19,262	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	EEV	Active	10 µF	±20%	25 V	1.93Ohm @ 100kHz	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	-	General Purpose	63 mA @ 120 Hz	90 mA @ 100 kHz	1.93 Ohms	-	0.157 Dia (4.00mm)	0.222 (5.65mm)	0.169 L x 0.169 W (4.30mm x 4.30mm)	Surface Mount
EEV106M035A9BAA CAP ALUM 10UF 20% 35V SMD KEMET	19,780	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	EEV	Active	10 µF	±20%	35 V	1.93Ohm @ 100kHz	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	-	General Purpose	63 mA @ 120 Hz	90 mA @ 100 kHz	1.93 Ohms	-	0.157 Dia (4.00mm)	0.222 (5.65mm)	0.169 L x 0.169 W (4.30mm x 4.30mm)	Surface Mount
35PK470MEFCT810X12.5 CAP ALUM 470UF 20% 35V RADIAL Rubycon	3,964	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	PK	Active	470 µF	±20%	35 V	-	2000 Hrs @ 85°C	-40°C ~ 85°C	Polar	-	General Purpose	680 mA @ 120 Hz	816 mA @ 10 kHz	-	0.197 (5.00mm)	0.394 Dia (10.00mm)	0.551 (14.00mm)	-	Through Hole
UVR1V471MPD1TD CAP ALUM 470UF 20% 35V RADIAL Nichicon	10,538	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	UVR	Not For New Designs	470 µF	±20%	35 V	-	2000 Hrs @ 85°C	-40°C ~ 85°C	Polar	-	General Purpose	650 mA @ 120 Hz	975 mA @ 10 kHz	-	0.197 (5.00mm)	0.394 Dia (10.00mm)	0.689 (17.50mm)	-	Through Hole
10WXA1000MEFCT810X9 CAP ALUM 1000UF 20% 10V RADIAL Rubycon	4,779	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	WXA	Active	1000 µF	±20%	10 V	-	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive	460 mA @ 120 Hz	-	-	0.197 (5.00mm)	0.394 Dia (10.00mm)	0.413 (10.50mm)	-	Through Hole
EEE-HBE100UAR CAP ALUM 10UF 20% 25V SMD Panasonic Electronic Components	4,221	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	HB	Active	10 µF	±20%	25 V	-	2000 Hrs @ 105°C	-40°C ~ 105°C	Polar	AEC-Q200	Automotive	28 mA @ 120 Hz	47.6 mA @ 10 kHz	-	-	0.157 Dia (4.00mm)	0.228 (5.80mm)	0.169 L x 0.169 W (4.30mm x 4.30mm)	Surface Mount
EEV107M016S9GAA CAP ALUM 100UF 20% 16V SMD KEMET	10,390	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	EEV	Active	100 µF	±20%	16 V	520mOhm @ 100kHz	2000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive	168 mA @ 120 Hz	240 mA @ 100 kHz	520 mOhms	-	0.248 Dia (6.30mm)	0.222 (5.65mm)	0.260 L x 0.260 W (6.60mm x 6.60mm)	Surface Mount
ECA-2CHG4R7B CAP ALUM 4.7UF 20% 160V RADIAL Panasonic Electronic Components	2,103	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	NHG-A	Active	4.7 µF	±20%	160 V	-	2000 Hrs @ 105°C	-25°C ~ 105°C	Polar	-	General Purpose	43 mA @ 120 Hz	64.5 mA @ 100 kHz	-	0.197 (5.00mm)	0.248 Dia (6.30mm)	0.480 (12.20mm)	-	Through Hole
EEU-FC1H470B CAP ALUM 47UF 20% 50V RADIAL Panasonic Electronic Components	8,343	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	FC	Active	47 µF	±20%	50 V	-	1000 Hrs @ 105°C	-55°C ~ 105°C	Polar	AEC-Q200	Automotive	169 mA @ 120 Hz	260 mA @ 100 kHz	600 mOhms	0.197 (5.00mm)	0.248 Dia (6.30mm)	0.579 (14.70mm)	-	Through Hole
