Aluminum - Polymer Capacitors- Page 26

MAX3232IDR PIC18F25K22T-I/SO 5-160558-2 ESD9B5.0ST5G

Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	Type	Capacitance	Tolerance	Voltage-Rated	ESR(EquivalentSeriesResistance)	Lifetime@Temp	OperatingTemperature	Ratings	Applications	Features	RippleCurrent@LowFrequency	RippleCurrent@HighFrequency	Impedance	LeadSpacing	Size/Dimension	Height-Seated(Max)	SurfaceMountLandSize	MountingType
HHSE500ELL121MJC5S CAP ALUM HYBRID 120UF 20% 50V TH United Chemi-Con	3,653	-	RFQ	Datasheet	Bulk	HSE	Active	Hybrid	120 µF	±20%	50 V	19mOhm	4000 Hrs @ 135°C	-55°C ~ 135°C	AEC-Q200	Automotive	-	350 mA @ 120 Hz	3.5 A @ 100 kHz	-	0.197 (5.00mm)	0.394 Dia (10.00mm)	0.551 (14.00mm)	-	Through Hole
PLF1C181MDO1TD CAP ALUM POLY 180UF 20% 16V T/H Nichicon	2,824	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	PLF	Active	Polymer	180 µF	±20%	16 V	9mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	-	5 A @ 100 kHz	-	0.138 (3.50mm)	0.315 Dia (8.00mm)	0.472 (12.00mm)	-	Through Hole
RPS0G221MCN1GS CAP ALUM POLY 220UF 20% 4V SMD Nichicon	2,979	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	FPCAP, RPS	Active	Polymer	220 µF	±20%	4 V	30mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	270 mA @ 120 Hz	2.7 A @ 100 kHz	-	-	0.315 Dia (8.00mm)	0.264 (6.70mm)	0.327 L x 0.327 W (8.30mm x 8.30mm)	Surface Mount
A765KN567M0JLAE012 CAP ALUM POLY 560UF 20% 6.3V SMD KEMET	2,891	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	A765	Active	Polymer	560 µF	±20%	6.3 V	12mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	250 mA @ 120 Hz	5 A @ 100 kHz	-	-	0.315 Dia (8.00mm)	0.394 (10.00mm)	0.327 L x 0.327 W (8.30mm x 8.30mm)	Surface Mount
RPS1C390MCN1GS CAP ALUM POLY 39UF 20% 16V SMD Nichicon	4,000	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	FPCAP, RPS	Active	Polymer	39 µF	±20%	16 V	45mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	200 mA @ 120 Hz	2 A @ 100 kHz	-	-	0.248 Dia (6.30mm)	0.224 (5.70mm)	0.256 L x 0.256 W (6.50mm x 6.50mm)	Surface Mount
A765KN227M1ALAE020 CAP ALUM POLY 220UF 20% 10V SMD KEMET	4,967	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	A765	Active	Polymer	220 µF	±20%	10 V	20mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	175 mA @ 120 Hz	3.5 A @ 100 kHz	-	-	0.315 Dia (8.00mm)	0.394 (10.00mm)	0.327 L x 0.327 W (8.30mm x 8.30mm)	Surface Mount
875105444001 CAP ALUM POLY 10UF 20% 20V SMD Würth Elektronik	2,322	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	WCAP-PSLP	Active	Polymer	10 µF	±20%	20 V	30mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	110 mA @ 120 Hz	2.2 A @ 100 kHz	-	-	0.248 Dia (6.30mm)	0.228 (5.80mm)	0.260 L x 0.260 W (6.60mm x 6.60mm)	Surface Mount
RL80E102MDN1KX CAP ALUM POLY 1000UF 2.5V T/H Nichicon	2,052	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	FPCAP, RL8	Active	Polymer	1000 µF	±20%	2.5 V	6mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	610 mA @ 120 Hz	6.1 A @ 100 kHz	-	0.138 (3.50mm)	0.315 Dia (8.00mm)	0.315 (8.00mm)	-	Through Hole
RS80E821MDNASQJT CAP ALUM POLY 820UF 20% 2.5V T/H Nichicon	2,118	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	FPCAP, RS8	Active	Polymer	820 µF	±20%	2.5 V	7mOhm	5000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	560 mA @ 120 Hz	5.6 A @ 100 kHz	-	0.098 (2.50mm)	0.248 Dia (6.30mm)	0.315 (8.00mm)	-	Through Hole
A765KN687M0JLAE012 CAP ALUM POLY 680UF 20% 6.3V SMD KEMET	4,165	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	A765	Active	Polymer	680 µF	±20%	6.3 V	12mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	250 mA @ 120 Hz	5 A @ 100 kHz	-	-	0.315 Dia (8.00mm)	0.394 (10.00mm)	0.327 L x 0.327 W (8.30mm x 8.30mm)	Surface Mount
RHA0E821MCN1GS CAP ALUM POLY 820UF 20% 2.5V SMD Nichicon	3,000	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	FPCAP, RHA	Active	Polymer	820 µF	±20%	2.5 V	8mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	500 mA @ 120 Hz	5 A @ 100 kHz	-	-	0.315 Dia (8.00mm)	0.264 (6.70mm)	0.327 L x 0.327 W (8.30mm x 8.30mm)	Surface Mount
RL80J561MDNASQKX CAP ALUM POLY 560UF 20% 6.3V T/H Nichicon	4,481	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	FPCAP, RL8	Active	Polymer	560 µF	±20%	6.3 V	8mOhm	5000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	570 mA @ 120 Hz	5.7 A @ 100 kHz	-	0.138 (3.50mm)	0.315 Dia (8.00mm)	0.315 (8.00mm)	-	Through Hole
ECASD40D227M009K00 CAP ALUM POLY 220UF 20% 2V SMD Murata Electronics	7,085	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	ECAS	Active	Polymer	220 µF	±20%	2 V	9mOhm	1000 Hrs @ 105°C	-40°C ~ 105°C	-	General Purpose	-	-	3 A @ 100 kHz	-	-	0.287 L x 0.169 W (7.30mm x 4.30mm)	0.075 (1.90mm)	0.287 L x 0.169 W (7.30mm x 4.30mm)	Surface Mount
APXA200ARA151MJC0G CAP ALUM POLY 150UF 20% 20V SMD United Chemi-Con	1,534	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	NPCAP™-PXA	Active	Polymer	150 µF	±20%	20 V	20mOhm	15000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	-	4.32 A @ 100 kHz	-	-	0.394 Dia (10.00mm)	0.492 (12.50mm)	0.406 L x 0.406 W (10.30mm x 10.30mm)	Surface Mount
RSL0E331MCN1GB CAP ALUM POLY 330UF 20% 2.5V SMD Nichicon	3,000	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	FPCAP, RSL	Active	Polymer	330 µF	±20%	2.5 V	16mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	350 mA @ 120 Hz	3.5 A @ 100 kHz	-	-	0.248 Dia (6.30mm)	0.165 (4.20mm)	0.256 L x 0.256 W (6.50mm x 6.50mm)	Surface Mount
RSA1C221MCN1GS CAP ALUM POLY 220UF 20% 16V SMD Nichicon	3,540	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	FPCAP, RSA	Active	Polymer	220 µF	±20%	16 V	20mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	350 mA @ 120 Hz	3.5 A @ 100 kHz	-	-	0.248 Dia (6.30mm)	0.315 (8.00mm)	0.260 L x 0.260 W (6.60mm x 6.60mm)	Surface Mount
RR50J681MDN1PH CAP ALUM POLY 680UF 20% 6.3V T/H Nichicon	2,480	-	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	FPCAP, RR5	Active	Polymer	680 µF	±20%	6.3 V	5mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	722 mA @ 120 Hz	7.22 A @ 100 kHz	-	0.197 (5.00mm)	0.394 Dia (10.00mm)	0.551 (14.00mm)	-	Through Hole
RHA0E102MCN1GS CAP ALUM POLY 1000UF 2.5V SMD Nichicon	5,085	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	FPCAP, RHA	Active	Polymer	1000 µF	±20%	2.5 V	8mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	500 mA @ 120 Hz	5 A @ 100 kHz	-	-	0.315 Dia (8.00mm)	0.303 (7.70mm)	0.327 L x 0.327 W (8.30mm x 8.30mm)	Surface Mount
A768KS397M1ELAE019 CAP ALUM POLY 390UF 20% 25V SMD KEMET	6,244	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	A768	Active	Polymer	390 µF	±20%	25 V	19mOhm	2000 Hrs @ 125°C	-55°C ~ 125°C	-	General Purpose	-	116.25 mA @ 120 Hz	2.325 A @ 100 kHz	-	-	0.315 Dia (8.00mm)	0.492 (12.50mm)	0.327 L x 0.327 W (8.30mm x 8.30mm)	Surface Mount
A765KH337M1ALAE017 CAP ALUM POLY 330UF 20% 10V SMD KEMET	6,554	-	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	A765	Active	Polymer	330 µF	±20%	10 V	17mOhm	2000 Hrs @ 105°C	-55°C ~ 105°C	-	General Purpose	-	117.5 mA @ 120 Hz	2.35 A @ 100 kHz	-	-	0.315 Dia (8.00mm)	0.307 (7.80mm)	0.327 L x 0.327 W (8.30mm x 8.30mm)	Surface Mount
