Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | IGBTType | Configuration | Voltage-CollectorEmitterBreakdown(Max) | Current-Collector(Ic)(Max) | Power-Max | Vce(on)(Max)@VgeIc | Current-CollectorCutoff(Max) | InputCapacitance(Cies)@Vce | Input | NTCThermistor | OperatingTemperature | MountingType |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
FF600R12ME4WB73BPSA1MEDIUM POWER ECONO |
3,775 | - |
RFQ |
Tray | EconoDUAL™ 3 | Active | Trench Field Stop | 2 Independent | 1200 V | 600 A | 20 mW | 2.1V @ 15V, 600A | 3 mA | 37 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | ||
FF900R12ME7B11NPSA1MEDIUM POWER ECONO |
2,296 | - |
RFQ |
Datasheet |
Tray | EconoDUAL™ 3 | Active | Trench Field Stop | 2 Independent | 1200 V | 900 A | 20 mW | 1.8V @ 15V, 900A | 100 µA | 122 nF @ 25 V | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | |
FF900R12ME7PB11BPSA1MEDIUM POWER ECONO |
2,608 | - |
RFQ |
Datasheet |
Tray | EconoDUAL™ 3 | Active | Trench Field Stop | Half Bridge | 1200 V | 900 A | - | 1.8V @ 15V, 900A | 100 µA | 122 nF @ 25 V | Standard | No | -40°C ~ 175°C | Chassis Mount | |
FP200R12N3T7B11BPSA1LOW POWER ECONO |
2,346 | - |
RFQ |
Datasheet |
Tray | EconoPIM™3 | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 200 A | 20 mW | 1.55V @ 15V, 200A | 20 µA | 40.3 nF @ 25 V | Three Phase Bridge Rectifier | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | |
FP200R12N3T7BPSA1LOW POWER ECONO AG-ECONO3-3 |
2,370 | - |
RFQ |
Tray | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | ||
FF900R12ME7WB11BPSA1MEDIUM POWER ECONO |
2,137 | - |
RFQ |
Tray | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | ||
FS150R12W3T7B11BPSA1LOW POWER EASY AG-EASY3B-1 |
3,195 | - |
RFQ |
Tray | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | ||
FP75R12W3T7B11BPSA1LOW POWER EASY AG-EASY3B-1 |
3,225 | - |
RFQ |
Tray | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | ||
FF400R12KT4HOSA1IGBT MODULE |
3,328 | - |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | ||
BSM600GA120DLCSIGBT MODULE |
3,427 | - |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | |
BSM400GA170DLSIGBT MODULE |
2,932 | - |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | |
DDB6U180N16RRB37BPSA1LOW POWER ECONO AG-ECONO2B-411 |
2,090 | - |
RFQ |
Datasheet |
Tray | EconoPACK™ 2 | Active | Trench Field Stop | Single Chopper | 1200 V | 100 A | 20 mW | 2.1V @ 15V, 100A | 1 mA | 6.2 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | |
FS150R07N3E4_B11IGBT MODULE |
3,468 | - |
RFQ |
Datasheet |
Bulk | - | Active | Trench Field Stop | Three Phase Inverter | 650 V | 150 A | 430 W | 1.95V @ 15V, 150A | 1 mA | 9.3 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | |
FF1200R17IP5BPSA1IGBT MOD 1700V 1200A 20MW |
2,080 | - |
RFQ |
Datasheet |
Tray | PrimePack™2 | Active | Trench Field Stop | Half Bridge | 1700 V | 1200 A | 20 mW | 2.3V @ 15V, 1200A | 5 mA | 68 nF @ 25 V | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | |
F3L400R07W3S5B11BPSA1LOW POWER EASY AG-EASY3B-1 |
2,542 | - |
RFQ |
Tray | * | Not For New Designs | - | - | - | - | - | - | - | - | - | - | - | - | ||
FF1200R17IP5PBPSA1IGBT |
2,698 | - |
RFQ |
Datasheet |
Tray | PrimePack™2 | Active | Trench Field Stop | Half Bridge | 1700 V | 1.2 kA | 20 mW | 2.3V @ 15V, 1200A | 10 mA | 68 nF @ 25 V | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | |
FZ1600R17HP4B2BOSA2IGBT MODULE 1700V 1600A |
2,605 | - |
RFQ |
Datasheet |
Tray | IHM-B | Active | Trench Field Stop | Single Switch | 1700 V | 1600 A | 10500 W | 2.25V @ 15V, 1.6kA | 5 mA | 130 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | |
FZ250R65KE3NPSA1IGBT MOD 6500V 500A 4800W |
2,785 | - |
RFQ |
Datasheet |
Tray | - | Active | - | Single | 6500 V | 500 A | 4800 W | 3.4V @ 15V, 250A | 5 mA | 69 nF @ 25 V | Standard | No | -50°C ~ 125°C | Chassis Mount | |
FZ825R33HE4DBPSA1HV B SINGLE SWITCH POWER MODULES |
2,927 | - |
RFQ |
Datasheet |
Tray | IHM-B | Active | Trench Field Stop | Single Switch | 3300 V | 825 A | 2.4 MW | 2.65V @ 15V, 825A | 5 mA | 93.5 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | |
FF1500R12IE5BPSA1IGBT MOD 1200V 1500A 20MW |
