Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | Type | Voltage-Max | Current-Max | Current-Hold(Ih)(Max) | Current-Trip(It) | TimetoTrip | Resistance-Initial(Ri)(Min) | Resistance-PostTrip(R1)(Max) | Resistance-25°C(Typ) | OperatingTemperature | Ratings | MountingType | Size/Dimension | Height-Seated(Max) | Thickness(Max) |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
RUEF160-2PTC RESET FUSE 30V 1.6A RADIAL |
14,969 | - |
RFQ |
Datasheet |
Radial, Disc | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, RUEF | Active | Polymeric | 30V | 100 A | 1.6 A | 3.2 A | 8 s | 30 mOhms | 110 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.350 L x 0.118 W (8.90mm x 3.00mm) | 0.598 (15.20mm) | - | |
30R090UPRPTC RESET FUSE 30V 900MA RADIAL |
3,508 | - |
RFQ |
Datasheet |
Radial, Disc | Cut Tape (CT),Tape & Box (TB) | POLY-FUSE®, 30R | Active | Polymeric | 30V | 40 A | 900 mA | 1.8 A | 5.9 s | 70 mOhms | 220 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.291 L x 0.118 W (7.40mm x 3.00mm) | 0.480 (12.20mm) | - | |
MICROSMD150F-2PTC RESET FUSE 6V 1.5A 1210 |
33,185 | - |
RFQ |
Datasheet |
1210 (3225 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, microSMD | Active | Polymeric | 6V | 40 A | 1.5 A | 3 A | 1 s | 40 mOhms | 110 mOhms | - | -40°C ~ 85°C | - | Surface Mount | 0.127 L x 0.102 W (3.22mm x 2.58mm) | - | 0.048 (1.22mm) | |
1210L150THWRPTC RESET FUSE 6V 1.5A 1210 |
5,425 | - |
RFQ |
Datasheet |
1210 (3225 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | POLY-FUSE®, 1210L | Active | Polymeric | 6V | 100 A | 1.5 A | 3 A | 300 ms | 40 mOhms | 110 mOhms | - | -40°C ~ 85°C | - | Surface Mount | 0.127 L x 0.102 W (3.22mm x 2.58mm) | - | 0.042 (1.07mm) | |
MINISMDC200F-2PTC RESET FUSE 8V 2A 1812 |
32,633 | - |
RFQ |
Datasheet |
1812 (4532 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, miniSMD | Active | Polymeric | 8V | 100 A | 2 A | 4 A | 5 s | 20 mOhms | 70 mOhms | - | -40°C ~ 85°C | - | Surface Mount | 0.179 L x 0.128 W (4.55mm x 3.24mm) | - | 0.048 (1.22mm) | |
30R110UPRPTC RESET FUSE 30V 1.1A RADIAL |
14,824 | - |
RFQ |
Datasheet |
Radial, Disc | Cut Tape (CT),Tape & Box (TB) | POLY-FUSE®, 30R | Active | Polymeric | 30V | 40 A | 1.1 A | 2.2 A | 6.6 s | 50 mOhms | 170 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.291 L x 0.118 W (7.40mm x 3.00mm) | 0.559 (14.20mm) | - | |
60R050XPRPTC RESET FUSE 60V 500MA RADIAL |
15,763 | - |
RFQ |
Datasheet |
Radial, Disc | Cut Tape (CT),Tape & Box (TB) | POLY-FUSE®, 60R | Active | Polymeric | 60V | 40 A | 500 mA | 1 A | 4 s | 500 mOhms | 1.17 Ohms | - | -40°C ~ 85°C | - | Through Hole | 0.311 Dia x 0.122 T (7.90mm x 3.10mm) | 0.539 (13.70mm) | - | |
RKEF050-APPTC RESET FUSE 60V 500MA RADIAL |
22,176 | - |
RFQ |
Datasheet |
Radial, Disc | Cut Tape (CT),Tape & Box (TB) | PolySwitch®, RKEF | Active | Polymeric | 60V | 40 A | 500 mA | 1 A | 800 ms | 320 mOhms | 900 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.280 L x 0.140 W (7.10mm x 3.56mm) | 0.450 (11.43mm) | - | |
RUEF160-APPTC RESET FUSE 30V 1.6A RADIAL |
4,958 | - |
RFQ |
Datasheet |
Radial, Disc | Cut Tape (CT),Tape & Box (TB) | PolySwitch®, RUEF | Active | Polymeric | 30V | 100 A | 1.6 A | 3.2 A | 8 s | 30 mOhms | 110 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.350 L x 0.118 W (8.90mm x 3.00mm) | 0.598 (15.20mm) | - | |
MINISMDC300F-2PTC RESET FUSE 6V 3A 1812 |
18,302 | - |
RFQ |
Datasheet |
1812 (4532 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, miniSMD | Active | Polymeric | 6V | 100 A | 3 A | 6 A | 5 s | 11 mOhms | 36 mOhms | - | -40°C ~ 85°C | - | Surface Mount | 0.179 L x 0.128 W (4.55mm x 3.24mm) | - | 0.030 (0.76mm) | |
MINISMDC150F/16-2PTC RESET FUSE 16V 1.5A 1812 |
17,348 | - |
RFQ |
Datasheet |
1812 (4532 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, miniSMD | Active | Polymeric | 16V | 100 A | 1.5 A | 2.8 A | 500 ms | 40 mOhms | 110 mOhms | - | -40°C ~ 85°C | - | Surface Mount | 0.181 L x 0.128 W (4.60mm x 3.24mm) | - | 0.019 (0.48mm) | |
1812L125/16DRPTC RESET FUSE 16V 1.25A 1812 |
19,401 | - |
RFQ |
Datasheet |
1812 (4532 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | POLY-FUSE®, 1812L | Active | Polymeric | 16V | 100 A | 1.25 A | 2.5 A | 400 ms | 50 mOhms | 140 mOhms | - | -40°C ~ 85°C | - | Surface Mount | 0.179 L x 0.128 W (4.55mm x 3.24mm) | - | 0.049 (1.25mm) | |
RKEF075-2PTC RESET FUSE 60V 750MA RADIAL |
8,817 | - |
RFQ |
Datasheet |
Radial, Disc | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, RKEF | Active | Polymeric | 60V | 40 A | 750 mA | 1.5 A | 1.5 s | 200 mOhms | 640 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.402 L x 0.118 W (10.20mm x 3.00mm) | 0.598 (15.20mm) | - | |
MICROSMD175F-2PTC RESET FUSE 6V 1.75A 1210 |
88,053 | - |
RFQ |
Datasheet |
1210 (3225 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, microSMD | Active | Polymeric | 6V | 40 A | 1.75 A | 3.5 A | 800 ms | 25 mOhms | 80 mOhms | - | -40°C ~ 85°C | - | Surface Mount | 0.127 L x 0.102 W (3.22mm x 2.58mm) | - | 0.030 (0.76mm) | |
MICROSMD075F-2PTC RESET FUSE 6V 750MA 1210 |
45,703 | - |
RFQ |
Datasheet |
1210 (3225 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, microSMD | Active | Polymeric | 6V | 40 A | 750 mA | 1.5 A | 100 ms | 110 mOhms | 400 mOhms | - | -40°C ~ 85°C | - | Surface Mount | 0.127 L x 0.102 W (3.22mm x 2.58mm) | - | 0.024 (0.62mm) | |
1210L035YRPTC RESET FUSE 6V 350MA 1210 |
8,060 | - |
RFQ |
Datasheet |
1210 (3225 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | POLY-FUSE®, 1210L | Active | Polymeric | 6V | 100 A | 350 mA | 700 mA | 200 ms | 320 mOhms | 1.3 Ohms | - | -40°C ~ 85°C | - | Surface Mount | 0.127 L x 0.102 W (3.22mm x 2.58mm) | - | 0.033 (0.85mm) | |
60R075XPRPTC RESET FUSE 60V 750MA RADIAL |
4,361 | - |
RFQ |
Datasheet |
Radial, Disc | Cut Tape (CT),Tape & Box (TB) | POLY-FUSE®, 60R | Active | Polymeric | 60V | 40 A | 750 mA | 1.5 A | 6.3 s | 250 mOhms | 600 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.402 Dia x 0.122 T (10.20mm x 3.10mm) | 0.591 (15.00mm) | - | |
RUEF250-2PTC RESET FUSE 30V 2.5A RADIAL |
5,635 | - |
RFQ |
Datasheet |
Radial, Disc | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, RUEF | Active | Polymeric | 30V | 100 A | 2.5 A | 5 A | 10.3 s | 20 mOhms | 70 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.449 L x 0.118 W (11.40mm x 3.00mm) | 0.720 (18.30mm) | - | |
RXEF090-2PTC RESET FUSE 72V 900MA RADIAL |
6,054 | - |
RFQ |
Datasheet |
Radial, Disc | Tape & Reel (TR),Tape & Reel (TR),Cut Tape (CT),Cut Tape (CT) | PolySwitch®, RXEF | Active | Polymeric | 72V | 40 A | 900 mA | 1.8 A | 7.2 s | 200 mOhms | 470 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.441 Dia x 0.118 T (11.20mm x 3.00mm) | 0.622 (15.80mm) | - | |
1812L200THPRPTC RESET FUSE 8V 2A 1812 |
12,250 | - |
RFQ |
Datasheet |
1812 (4532 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | POLY-FUSE®, 1812L | Active | Polymeric | 8V | 100 A | 2 A | 3.5 A | 2 s | 20 mOhms | 70 mOhms | - | -40°C ~ 85°C | - | Surface Mount | 0.179 L x 0.128 W (4.55mm x 3.24mm) | - | 0.024 (0.60mm) |
